Bose L1 Pro16 Service Manual

20
MAIN-I/O PCB PARTS LIST
Resistors
Reference Designator Description Material Number Note
R103 RES, THICK FILM, 0603, 0.1W, 1%, 5.6K 857326-0166
R113 RES, THICK FILM, 0402, 0.063W, 1%, 6.8K 857326-0084
R116, R172, R320, R327,
R329, R336, R367, R371,
R387, R389-R390, R393,
R396, R398, R422
RES, THICK FILM, 0402, 0.063W, 1%, 10 OHM 857326-0089
R118, R167 RES, THICK FILM, 0402, 0.063W, 1%, 22K 857326-0045
R150, R286, R314, R318,
R322, R414, R231A,
R231B, R248A, R248B
RES, THICK FILM, 0603, 0.1W, 1%, 10K 857326-0093
R160-R161 RES, THICK FILM, 0603, 0.1W, 1%, 33 OHM 857326-0146
R169, R179 RES, THICK FILM, 0402, 0.063W, 1%, 100K 857326-0022
R186 RES, THICK FILM, 0402, 0.063W, 1%, 200
OHM
857326-0037
R196A, R196B, R205A,
R205B
RES, THICK FILM, 0603, 0.1W, 1%, 1.5K 857326-0108
R197A, R197B, R206A,
R206B
RES, THICK FILM, 0603, 0.1W, 1%, 22 OHM 857326-0130
R199A, R199B, R203A,
R203B, R219A, R219B,
R240A, R240B
RES, THICK FILM, 0603, 0.1W, 1%, 1M 857326-0095
R1-R2, R5-R8, R16-R29,
R32-R34, R91, R94,
R108-R111, R119-R121,
R137, R140, R153,
R268, R293, R296-R297,
R312-R313, R316, R321,
R338, R358-R359,
R361-R362, R369, R394,
R399, R401-R404,
R428-R430, R432-R434,
R436-R437, R440, R442,
R444-R445, R449-R452,
R468
JUMPER, CHIP, 0402 857326-0217
R200A, R200B, R204A,
R204B
RES, THICK FILM, 0603, 0.1W, 1%, 10M 857326-0096
R214A, R214B, R237A,
R237B
RES, THICK FILM, 0603, 0.1W, 1%, 3K 857326-0140
R215A, R215B, R223A,
R223B, R245A, R245B,
R254A, R254B
RES, THICK FILM, 0603, 0.1W, 1%, 1.2K 857326-0100
R216A, R216B, R224A,
R224B, R246A, R246B,
R255A, R255B
RES, THICK FILM, 0603, 0.1W, 1%, 24 OHM 857326-0133
R221A, R221B, R238A,
R238B
RES, THICK FILM, 0603, 0.1W, 1%, 3.6K 857326-0149
R222A, R222B, R242A,
R242B
RES, THICK FILM, 0603, 0.1W, 1%, 330 OHM 857326-0143
R226A, R226B, R235A,
R235B
RES, THICK FILM, 0603, 0.1W, 1%, 6.8K 857326-0171
