Bose L1 Pro16 Service Manual

10
Main Part List
L1 Pro16 Power Stand (see Figure 2)
Item
Number
Description Material
Number
Vendor Part
Number
Qty/Note
1 NON WOVEN SHEET FOR GRILLE 1 - T182900003140
2 NON WOVEN SHEET FOR GRILLE
LONG
- T182900003150
3 LINT SHEET FOR GRILLE 1 - T182900003130
4 POWER STAND GRILLE 861930-011S T130207800100
5 RUBBER BUMPER - T180200016480
6 WF CABLE 4P 3.96 VH-4Y-32 K - T641700186500
7 SCREW T4.0XL20 3.18P
BZN+CED COATING
- T15340201F600
8 RUBBER SHEET_GRILLE TOP MID - T180200017570
9 RUBBER SHEET_GRILLE TOP LR - T180200017560
10 SCREW T4.0XL20 2.3P
ZINC+CED COAT K
- T15340201F631
11 GASKET FOR WOODEN BRACKET
TOP
- T180500031330
12 CABINET LEFT - T100425300100
13 POWER WADDING - T182700002510
14 BRACKET - T130207500100
15 FOAM STRIP TOP - T180200015790
16 SCREW T4.0XL25 3.18P
BZN+CED COATING
- T15340251F600
17
SCREW, T3.5xL14 - T15335142F610
18 COVER SEAL ARRAY CONNECTOR - T100424300100
19 SOLDER LUG OD8.0*ID4.1*L56 G - T690300045600
20 GASKET FOR ENDCAP SEAL COV-
ER
- T180500031060
21 TW1+EQ CABLE 6PIN MOLEX
42474-6Y-VH-04 K
- T61700176200
22 VOL CONNECT CABLE 10PIN
ZH-11Y-ZH-03 K
- T641700180100
23 SCREW, M8xL30 - T15180302F410
24 FLAT WASHER M8 - T181200000590
25 SPRING WASHER, M8 - T181200000740
26 END CAP TOP - T100425600100
27 GASKET FOR HANDLE A - T180500032720
28 HANDLE - T100403900100
29 GASKET FOR HANDLE B - T180500032710
30 NUT (FOR HANDLE) - T181000000660

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
