Bose L1 Pro16 Service Manual

11
Main Part List
L1 Pro16 Power Stand (see Figure 2)
Item
Number
Description
Material
Number
Vendor Part
Number
Qty/Note
31 INLAY VOLUME SHEET - T180700009350
32 VOLUME KNOB 841657-0110 T100403800100
33 RUBBER RING - T180200016500
34 GASKET VOLUME PCB 1 - T180500031000
35 BRACKET VOLUME PCB - T100402800100
36 GASKET VOLUME PCB 2 - T180500033870
37 PCB SUBASSY, VOLUME, SVCE 861359-001S T910000074760
38 VOL CONNECT CABLE 10PIN
ZH-10Y-ZH-08 K
- T641700180000
39 GASKET_ANTENNA BRACKET - T180500031200
40 ANTENNA BRACKET - T100424500100
41 SCREW T3xL16_FLAT - T151301630610
42 AMP_MAIN PCBA ASSY - T910000075290
43 SPRING WASHER, M4 - -
44 SCREW, T4xL16 - T15340161F610
45 LINT SHEET FOR METAL BRACKET - T180000009230
46 FOAM STRIP FRONT - T180200015780
47 NON WOVEN
SHEET_BLACK_ADHESIVE
- T182900003120
48 CABINET RIGHT - T100425400100
49 GASKET FOR WOODEN BRACKET - T180500031080
50 WOOD BRACKET 2 - T180400001000
51 WOOD BRACKET - T180400001010
52
CURVED PORT - T100425500100
53 GASKET_CABINET_BOTTOM - T180500031350
54 WADDING PORT 20KG\M3 - T182700002670
55 FOAM STRIP BOTTOM - T180200015800
56 GASKET_END CAP BOTTOM &
CABINET
- T180500031360
57 GASKET_PORT RIGHT - T180500031300
58 GASKET_END CAP BOTTOM &
CABINET
- T180500031340
59 END CAP BOTTOM - T100425700100
60 BOTTOM SHEET RIGHT 857290-0120 T180700009420
61 BOTTOM SHEET_PC 861137-0110 T180700009950
62 PRODUCT LABEL 857291-0110 T180700009570
3
63 FEET RIGHT - T180200016540

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
