Bose L1 Pro16 Service Manual

12
Main Part List
L1 Pro16 Power Stand (see Figure 2)
Item
Number
Description
Material
Number
Vendor Part
Number
Qty/Note
64 BOTTOM SHEET LEFT 857290-0110 T180700009410
65 FEET LEFT - T180200016530
66 SCREW T4.0XL10 1.41P BZN+CED
COATING
- T15340101F611
67 GASKET PORT SUPPORT - T180500031040
68 GASKET_PORT CENTER - T180500031320
69 GASKET_PORT LEFT - T180500031310
70 WOOFER, RT LARGE 830125-0110 T911600011320
3
54
38
22
16
12
7
3
2
4
70
69
65
64
66
67
59
63
68
62
60
57
58
56
53
55
48
13
52
51
46
16
49
50
41
17
40
21
39
34
32
23
31
17
35
29
36
28
14
27
30
26
24
20
25
15
18
11
19
6
16
16
44
44
7
10
5
47
45
33
61
16
37
42
43
9
8
17
19
1
71
Figure 2. L1 Pro16 Power Stand Exploded View

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
