Bose L1 Pro16 Service Manual

35
POWER AMP PCB PARTS LIST
Miscellaneous
Reference Designator Description Material Number Note
F1 FUSE, 12A, 250V, SLO-BLO, 5x20mm, AXIAL 317834-123B 3
J1
CONN, HDR, 3.96mm C, 2P, 1R, P, TH, RA,
WHITE 847740-0020
J2
CONN, HDR, 2.54mm C, 28P, 2R, P, TH, ST,
45.8H 847836-0028
J3
CONN, HDR, 3.96mm C, 4P, 1R, P, TH, RA,
WHITE 847740-0040
J4
CONN, HDR, 3.96mm C, 2P, 1R, P, TH, ST,
WHITE 847743-0020
J5-J6 CONN, HDR, 1.25mm C, 4P, 1R, P, SMT, ST 845374-0401
J7 CONN, HDR, 2mm C, 2P, 1R, P, SMT, ST 847747-0020
K1 RELAY, POWER, 10A, 1a/1c, CLASS B INS 850873-0020 3
L12
INDUCTOR, POWER, SMT, 2.5A, 20%, 22uH,
COMM 853388-220M
L2, L7 INDUCTOR, CUSTOM, RADIAL, 85uH 852652-0010 3
L4-L6
INDUCTOR, CUSTOM, RADIAL, 15mm
HEIGHT, 8.5mH
852653-0010 3
T1 TRANSFORMER, CUSTOM, HTS-EEL25A 852657-0010 3
T2
TRANSFORMER, SWITCH, CUSTOM, HTS-
ER49B
852656-0010 3

Bose L1 Pro16 Specifications

General

Amplifier class	D
Frequency range	- Hz
RMS rated power	1250 W
Subwoofer peak power	1000 W
Sound pressure level (max)	124 dB
Amplifier	Built-in
Speaker type	-
Number of drivers	16
Built-in subwoofer	Yes
Subwoofer driver diameter (imperial)	18 \
Type	Freestanding Public Address (PA) system
Mounting type	Floor
Product color	Black
Volume control	Rotary
Number of mixer channels	3 channels
Connectivity technology	Wired & Wireless
6.35 mm (1⁄4-inch) input	1
Power source type	AC

Weight and Dimensions

Depth	456 mm
Width	355 mm
Height	2012 mm
Weight	24800 g
