Bose L1 Pro32 Service Manual

12
Main Part List
L1 Pro32 Power Stand (see Figure 2)
Item
Number
Description Material Number Vendor Part
Number
Note
24 BOTTOM COVER PC SHEET FRONT
L117.8 K
852458-0110 T180700009480
25 RUBBER FEET, FRONT LEFT 852453-0110 T100429800100
26 RUBBER FEET, FRONT RIGHT 852454-0110 T100429900100
27 HEATSINK AMP CHI AL6063 NATUR
COLOR K
- T130204100100
28 BOTTOM COVER PC SHEET LEFT
L355.2X K
852450-0110 T180700009490
29 BOTTOM COVER PRODUCT LABEL
PC K
- T180700009600
30 BOTTOM COVER PC SHEET RIGHT
L355.2 K
852450-0120 T180700009500
31 SCREW T3.0XL12 1.06P NICKEL
PLATE K
- T15330122F610
32 SCREW T3.5XL10 - K - T15335101F610
33 RELAY 250V 250V 30A 35. HF37F\012
K
- T690400001200
34 RUBBER FEET, REAR, LEFT 852452-0110 T100429700100
35 RUBBER FEET, REAR, RIGHT 852451-0110 T100429600100
36 SCREW T3.0XL18 1.058P
BZN+CED+HT K
- T15330181F610
37 SMPS, HARNESS - T641700182900
38 1P YELLOW\GREEN 16AWG UL1015
X-P-1966 K
- T641700171600
39 TUBE PVC 30 38 - K - T690200008700
40 EVA_38 DEGREE_BLACK_ADHESIVE
DS11 K
- T180500030670
41 NUT M3.0X0.5PXOD5.5XL2.3 NICKEL
PLATE K
- T181000000520
42 PLUG 250VA 10A NA JINJIA K - T691200007600
43 SCREW M3XL12MM 0.5P ZINC+NICK-
EL K
- T151301230611-
02
44 COOLING FAN 5V 0.05A 40*40*1
5000PRM AXIAL K
841436-0110 T691300000400
45 BASE MATCH CABLE 05RMFS-PH-
2Y-03 K
847615-0010 T641700182800
46 EMI BEAD CKT3612B K - T710500035000

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
