Bose L1 Pro32 Service Manual

16
Main Part List
L1 Pro32 Array Speaker (see Figure 3)
Item
Number
Description Material Number
Vendor Part
Number
Note
1 GRILLE, ARRAY SUBASSY, UPPER,
SVCE
864750-011S T130210300100
2 WASHER, SUS 304 - T181200001410
3 TAPE, DOUBLE, DX6930 - T180000008760
4 LOGO, ARRAY - T100424600100
5 SCREW, T3XL10 - T15330101F611
6 METAL SHEET, L16, SPCC - T13020810010A
7 SPONGE, YU356, ADHESIVE, 3212 - T180500028000
8 PE FOAM, ADHESIVE, BLACK, DS11 - T180500031050
9 SCREW, T3XL15 - T15330151F610
10 ENCLOSURE, ABS, BLACK - T100426300100
11 WADDING, ARRAY - T182700002500
12 CABLE, ARRAY2-2 - T641700172200
13 CABLE, ARRAY, 6PIN - T641700171100
14 CABLE, SINGLE, TW CONNECT,
120MM
- T641700168700
15 SILICON FOAM, 25 DEGREE - T180200015730
16 SILICON FOAM, 25 DEGREE - T180200015810
17
SCREW, T3XL12 -
T153301230610-
02
18 ENDCAP, 1 (TOP, UPPER ARRAY) 826315-0110 T910400038740
19 NON WOVEN, ADHESIVE, BLACK, 3M
9448HKB
- T182900003220
20 GASKET, END CAP, TOP 839673-0110 T910400040060
21 NON WOVEN, ADHESIVE, BLACK,
DS11
- T182900003190
22 BAFFLE, UPPER, ABS, BLACK - T100426200100
23 NON WOVEN, ADHESIVE, BLACK,
DS11
- T182900003140
24 NUT SPRING, M3 - T181000001460
25 SCREW, M3XL12MM - T151301210610
26 ENDCAP, 2 (UPPER ARRAY) 813543-0110 T910400040050
27 LABEL, ARRAY, ASSY - T911700056750
28 GRILLE, ARRAY, LOWER 831643-0110 T910400040030
29 CABLE, ARRAY, 8PIN - T641700170700
30 SHIM, ARRAY - T100430400100
31 ENCLOSURE CURVED, ARRAY - T100430100100

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
