Bose L1 Pro32 Service Manual

11
Main Part List
L1 Pro32 Power Stand (see Figure 2)
Item
Number
Description Material Number Vendor Part
Number
Note
1 PC SHEET TOP COVER L463X-
W262.45MM K
843967-0110 T180700009510
2 TOP COVER PP 94V0 BLACK K - T100424800100
3 BRACKET VOLUME P PC+ABS 94V0
BLACK K
- T100402800100
4 GASKET VOLOUME PCB1 K - T180500034490
5 VOLUME PCBA 861359-001S T910000074760
6 ANTENNA BRACKET PC+ABS 94V0
BLACK K
- T100424500100
7 ASSY, PCB, ANTENNA AND CABLE 796036-001S T690800019100
8 VOL CONNECT CABLE 10PIN ZH-10Y-
ZH-07 K
- T641700179800
9 VOL CONNECT CABLE 11PIN ZH-11Y-
ZH-04 K
- T641700174500
10 PP SHEET ADHESIVE DS11
L112.5XW62. K
- T180700009520
11 SCREW T4.0XL18 1.75P BZN+CED+HT
K
- T15340181F611
12 SCREW M3.0XL9 0.5P BLUE
ZINC+NYL K
- T15130091C610
13 SCREW M5XL25 0.8P_NYLOK_CED
COA K
- T15150251F610
14 WASHER OD9.7XID6.4XT1.7 STEEL
CED K
- T181200000310
15 PLATE HEATSINK P AL1050 NATUR
COLOR K
- T130203100100
16 WASHER OD5.0XID3.1XT2.0 STEEL
NICKEL L
- T181200000270
17 BRACKET AL ALLOY NATUR PASSIV K - T130210200100
18 HANDLE PP 94V0 BLACK K - T100425000100
19 THERMAL PAD 2_THERMAL CONDUC-
TIVE FA K
- T181700001640
20 POWER-AMP PCBA 864694-001S T910000074780
21 ARRAY CAVITY HARNESS 847608-0110 T641700170600
22 BOTTOM COVER PP 94V0 BLACK K - T100424900100
23 SCREW T4.0XL15 1.41P BLUE ZINC+C
K
- T15001111F610

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
