Bose L1 Pro32 Service Manual

14
Item
Number
Description Material Number
Vendor Part
Number
Note
70 POLARITY LIGHT G KINGFA JH 94V2
MILK K
- T100402300100
71 BUTTON SELECTION PC+ABS 94V0
BLACK K
- T100402900100
72 BUTTON MUTE PC 94V2 MILK L - T100403300200
73 AMP EMI SHIE SECC NATUR COLOR
K
- T130202600100
74 SCREW T3.0XL15 1.27P ZINC+CED
COA K
- T15330151F610
75 SCREW T3XL12 P1.058 ZINC+NI K - T153301230610-
02
76 MAIN CONNECT SMPS CABLE IDC-
28Y-IDC-C3 K
- T641700171700
77 6.35MM STEREO JACK NJ6FD-V K - T710200019500
78 VOLUME KNOB ABS PA-75 94HB
BLACK K
841657-0110 T100403800100
79 RUBBER RING_SILICON 50 DEGREE_
BLACK K
- T180200016500
80 SCREW M5.0XL9 0.8P BZN+CED+HT K - T15150092F610
81 SOLDER LUG OD8.0*ID4.1*L56 K - T690300045600
82 NON WOVEN SHEET_BLACK_ADHE-
SIVE 3M9 K
- T182900003120
83 SCREW T3XL6 1.3P_NICKEL PLATIN K - T153300612631
84 THERMAL GREASE TG3500 K - T980200002400
NA GAP FILLER, THERMAL, ONE PART,
55CC
749859-0020 -
Main Part List
L1 Pro32 Power Stand (see Figure 2)

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
