Bose L1 Pro32 Service Manual

26
MAIN-I/O PCB PARTS LIST
Miscellaneous
Reference Designator Description Material Number Note
CN1 CONN, RECP, 1.27mm C, 16P, 2R, R, SMT, ST 847826-0016
J1 CONN, RECP, 1.27mm C, 10P, 2R, R, SMT, ST 847826-0010
J16B CONN, RECP, 1.5mm C, 11P, 1R, R, SMT, RA,
BEIGE
847823-0011
J17B CONN, RECP, 1.5mm C, 10P, 1R, R, SMT, RA,
BEIGE
847823-0010
J18B CONN, RECP, 1.5mm C, 8P, 1R, R, SMT, RA,
BEIGE
847823-0008
J19A, J19B CONN, IO, XLR, 3POLE, ST, R, PCB Mount 850870-0010
J2 CONN, RECP, 2mm C, 2P, 1R, R, SMT, ST 847824-0002
J21 CONN, HDR, 2.5mm C, 2P, 1R, P, SMT, ST 853441-0002
J22B CONN, HDR, 2.54mm C, 28P, 2R, P, SMT, ST,
BLACK
847830-0028
J4 CONN, IO, 6.35MM STERIO JACK, R, ST, PCB
MOUN
849858-0010
J5 CONN, IO, 3POLE XLR, P, Sel Gold 763327-0120
T1 TRANSFORMER, AUDIO, DIGITAL, DIL, 1mH 856463-0010 3
SW1-SW2, SW4, SW6-
SW10
SWITCH, TACT, 12V, 50mA, 250gf 850862-0010
SW3 SWITCH, TACT, 15V, 20mA, 320GF 854394-0010

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
