POWER-AMP PCB PARTS LIST
Miscellaneous
Reference Designator Description Material Number Note
F1 FUSE, 8A, 250V, SLO-BLO, 5x20mm, AXIAL 317834-083B 3
J2 CONN, HDR, 2.54mm C, 28P, 2R, P, TH, ST,
BLACK
847835-0028
J3 CONN, HDR, 2mm C, 2P, 1R, P, SMT, ST 847747-0020
J5 CONN, HDR, 1.25mm C, 4P, 1R, P, SMT, ST 845374-0401
J6 CONN, HDR, 3.96mm C, 2P, 1R, P, TH, RA,
WHITE
847740-0020
RT1 THERMISTOR, NTC, ICL, BULK, 20%, 10 ohm 856032-100MB 3
RT2 VARISTOR, METAL OXIDE, DIA 14mm,
300Vrms
856832-3000D 3
RT3-RT4 THERMISTOR, NTC, 0603, 3380K, 1%, 10K 855644-103F
T1 TRANSFORMER, CUSTOM, HTS-EEL25A 852657-0010 3
T2 TRANSFORMER, SWITCH, CUSTOM, HTS-
ER40F
852655-0010 3

Bose L1 Pro32 Specifications

General

Coverage Pattern	180° H x 0° V
Bluetooth	Yes
Battery Life	Not applicable
Type	Portable Line Array System
Maximum SPL	126dB
System Power	2000W peak
Inputs	2 x XLR-1/4" combo
Outputs	XLR line output
