Bose Powered Acoustimass 30 User Manual

35
MAIN PART LIST
(see Figures 20 and 21)
Item
Number
Desciption Part
Number
Qty Note
1 COVER, AM9P, REG, WHITE
COVER, AM9P, REG, BLACK
172278-11
172278-12
1
2 KNOB, TONE CONTROL, WHITE
KNOB, TONE CONTROL, BLACK
172289-1
172289-2
2
3 LATCH, COVER 172294 1
4 BASE PLATE 172288 1
5 PCB ASSY, AM-30P, 120V
PCB ASSY, AM-30P, 230V
PCB ASSY, AM-30P, 120/230V
193133-1
193133-2
193133-6
1 changed 5/02
6 BRACKET, ADAPTOR 172287 1
7 SCREW, HI-LO, 6x3/8, PAN HEAD 147516-06 6
8 CABLE, FFC, 16 POS. 191124-16 1
9 HARNESS, WOOFER 172275 1
10 HEATSINK 172283 1
11 PLATE, HEATSINK, METAL 172291 1
12 PLATE, SPRING 172281 1
13 GROMMET, BASE PLATE 172295 2
14 TRANSFORMER, 115/230V 182577 1 3
15 CUSHION, TRANSFORMER 176169 2
16 GASKET, CONNECTOR, COVER 186845 1
17 SCREW, TAPP, 8-11x1.25, PAN, XRC/S 172672-20 8
18 MODULE ASSY, AM-30P, 120V
MODULE ASSY, AM-30P, 230V
MODULE ASSY, AM-30P, DUAL
193134-131C
193134-231C
193134-631C
1
19 SCREW, TAPP, 8-11x.75, PAN, XRC/SQ 172672-12 8
20 WOOFER ASSY, 5.1/4" 172276 2
21 GASKET, 6.5" WOOFER 104794-08 2
22 GASKET, TAPE 175548 2
23 CAP,PORT, BLACK
CAP,PORT, WHITE
173310-1
173310-2
1
24 PORT, BOTTOM, BLACK
PORT, BOTTOM, WHITE
173312-1
173312-2
1
25 PORT SCREEN 145325 1
26 BUMPER, RECESSED, FOOT, .88" 142839 4
27 SCREW, HILO, 6-20X.625, PANHD, XRC 172779-10 2
28 ANCHOR, SCREW, #6, PLASTIC 186207 2
29 GASKET, TAPE, FOAM, PCB 174676 1
30 TAPE, FOAM 2" 134936-020 1
31 FOAM TAPE, 8" 134936-080 1
- PORT, FLARE, 1.56"ID 189822-001 1
