37
ELECTRICAL PART LIST
Reference
Designator
Description Part
Number
Note
R3, 4, 129, 190, 192, 229, 290, 292,
384, 610, 619, 622, 631-633, 642, 709,
715, 731
10.0kΩ, CHIP, 0805, 5% 133626-1035
R7, 13, 15 20kΩ, CHIP, 0805, 5% 133626-2035
R9, 196, 296, 376, 394, 609, 618, 629 1MΩ, CHIP, 0805, 5% 133626-1055
R10, 12, 108, 111, 114, 118, 125, 126,
155, 181, 183, 186, 188, 189, 191, 195,
208, 211, 214, 218, 225, 226, 255, 281,
283, 286, 288, 289, 291, 295, 307, 388,
389, 396, 397, 455, 461, 551, 555, 560,
561, 607, 617, 627, 734, 736, 737
1.00KΩ, CHIP, 0805, 1% 133625-1001
R11, 119, 122, 180, 185, 194, 219,
222, 280, 285, 294, 322, 378, 380, 387,
494, 594, 606, 614, 630
100kΩ, CHIP, 0805, 5% 133626-1045
R16, 17, 401, 501 8.25kΩ, CHIP, 0805, 1% 133625-8251
R18, 20, 110, 210 4.42kΩ, CHIP, 0805, 1% 133625-4421
R19, 21, 620, 623, 733, 735 499Ω, CHIP, 0805, 1% 133625-4990
R51, 137, 237, 315, 324, 413, 457,
513, 557
10Ω, CHIP, 0805, 5% 133626-1005
R104, 105, 197, 204, 205, 297, 301,
303, 497, 597
6.81kΩ, CHIP, 0805, 1% 133625-6811
R106, 123, 134, 135, 206, 223, 231,
235, 611, 616, 710
2.00kΩ, CHIP, 0805, 1% 133625-2001
R107, 109, 207, 209, 309, 408, 409,
508, 509, 564, 602, 605, 612, 636
4.02kΩ, CHIP, 0805, 1% 133625-4021
R112, 113, 212, 213 44.2kΩ, CHIP, 0805, 1% 133625-4422
R115, 116, 215, 216 1.82kΩ, 0805, 1/10W, 1% 133625-1821
R117, 217 14.0kΩ, CHIP, 0805, 1% 133625-1402
R120, 150, 184, 193, 220, 250, 284,
293, 460
1.50kΩ, CHIP, 0805, 1% 133625-1501
R121, 124, 151, 175, 177, 221, 224,
251, 275, 277, 381, 385, 475, 477, 575,
577, 708, 721, 722
3.01kΩ, CHIP, 0805, 1% 133625-3011
R127, 128, 227, 228, 407, 507, 553,
604
20.0kΩ, CHIP, 0805, 1% 133625-2002
R138, 238, 311, 320, 321, 377, 625 301Ω, CHIP, 0805, 1% 133625-3010
R152, 252, 319 127kΩ, 0805, 1/10W, 1% 133625-1272
R153, 164, 253, 264 19.1kΩ, 0805, 1/10W, 1% 133625-1912
R154, 254 53.6kΩ, 0805, 1/10W, 1% 133625-5362
R156, 256, 456, 463, 563, 634 10.0kΩ, CHIP, 0805, 1% 133625-1002
R157, 160, 257, 260 1.40kΩ, CHIP, 0805, 1% 133625-1401
R159, 259, 383 200kΩ, 0805, 1/10W, 1% 133625-2003
R161, 261 1.10kΩ, 0805, 1/10W, 1% 133625-1101
R162, 262, 462 25.5kΩ, 0805, 1/10W, 1% 133625-2552
R163, 263 12.7kΩ, 0805, 1/10W, 1% 133625-1272
Resistors
To Next Page
