ELECTRICAL PART LIST
Resistors (continued)
Reference
Designator
Description Part
Number
Note
R165, 265, 453, 511, 514, 515 23.7kΩ, 0805, 1/10W, 1% 133625-2372
R166, 266 1.47kΩ, 0805, 1/10W, 1% 133625-1471
R176, 276, 375, 476, 576 16.5kΩ, CHIP, 0805, 1% 133625-1652
R178, 179, 278, 279, 312, 313, 399,
478, 479, 578, 579, 641, 643
49.9kΩ, CHIP, 0805, 1% 133625-4992
R182, 187 4.22kΩ, 1206, 1/8W, 1% 124894-4221
R282, 287 3.65kΩ, 1206, 1/8W, 1% 124894-3651
R302, 304 1.27kΩ, CHIP, 0805, 1% 133625-1271
R305 61.9kΩ, CHIP, 0805, 1% 133625-6192
R310 332kΩ, CHIP, 0805, 1% 133625-3323
R316 162kΩ, CHIP, 0805, 1% 133625-1623
R317, 516, 601, 635 27.4kΩ, CHIP, 0805, 1% 133625-2742
R318 150kΩ, 0805, 1/10W, 1% 133625-1503
R379 10MΩ, CHIP, 0805, 5% 133626-1065
R382 200Ω, CHIP, 0805, 5% 133626-2015
R390, 395 75Ω,CHIP, 0805, 5% 133626-7505
R391 JUMPER, CHIP, 0805 133627
R392, 648 220Ω,0805, 1/10W, 5% 133626-2215
R393 5.1Ω, 1206, 1/8W, 5% 124895-5R15
R398, 600 33.2kΩ, CHIP, 0805, 1% 133625-3322
R404, 504 15.8kΩ, CHIP, 0805, 1% 133625-1582
R405, 505 24.3kΩ, CHIP, 0805, 1% 133625-2432
R410, 411 73.2kΩ, CHIP, 0805, 1% 133625-7322
R450, 566 2.21kΩ, CHIP, 0805, 1% 133625-2211
R451 2.74kΩ, 0805, 1/10W, 1% 133625-2741
R452 68.1kΩ, 0805, 1/10W, 1% 133625-6812
R454, 554 38.3kΩ, 0805, 1/10W, 1% 133625-3832
R459, 552 100kΩ, 0805, 1/10W, 1% 133625-1003
R464, 562 21.0kΩ, 0805, 1/10W, 1% 133625-2102
R466 2.32kΩ, 0805, 1/10W, 1% 133625-2321
R510 78.7kΩ, 0805, 1/10W, 1% 133625-7872
R550 1.33kΩ, 0805, 1/10W, 1% 133625-1331
R559 93.1kΩ, 0805, 1/10W, 1% 133625-9312
R603 200kΩ, CHIP, 0805, 5% 133626-2045
R615 9.1kΩ, CHIP, 0805, 5% 133626-9125
R626 39Ω, 1206, 1/8W, 5% 124895-3905
R628, 640 JUMPER, CHIP, 1206 124896
R646, 647, 649 1.00kΩ, 0805, 1/10W, 5% 133625-1025
