39
ELECTRICAL PART LIST
Reference
Designator
Description Part
Number
Note
C1, 2, 123, 223, 407, 507 .033uF, 0805, X7R, 50V,
10%
133623-333
C3, 4 4700uF, EL, BP, 85, 50V,
20%
187394
C5, 6, 11, 12, 18-20, 28-43, 46-51, 54,
55, 58, 59, 185, 285, 375, 379-381,
485, 585, 601, 610, 710-717
.10uF, 0805, Y5V, 25V,
80%
133624
C7 4700uF, EL, 85, 25V, 20% 170216
C8, 14 2200uF, EL, 85, 20% 185929-222E
C9, 10, 13, 15-17, 109, 117, 184, 209,
217, 284, 401, 403, 476, 484, 501, 503,
576, 584, 600, 700-709
10uF, EL, 20% 137126-100
C22-25, 161, 177, 178, 180, 182, 261,
277, 278, 280, 282, 309, 383, 386, 461,
477, 478, 561, 577, 578
1000pF, 0805, X7R, 50V,
10%
133623-102
C62, 63, 65, 179, 183, 279, 283, 384,
609, 611, 614, 616, 618
.01uF, 0805, X7R, 50V,
10%
133623-103
C102, 103, 202, 203, 382, 387 3300pF, 0805, X7R, 50V,
10%
133623-332
C104, 162, 186, 204, 262, 286, 615,
621-625
100pF, 0805, COG, 50V,
5%
133622-101
C105, 106, 153, 205, 206, 253 .047uF, BOX, 85, 63V, 5% 137127-473
C107, 207 .027uF, BOX, 85, 100V, 5% 137127-273
C108, 208 330pF, CER, 10%, 50V 140564-331
C113, 213 .39uF, BOX, 85, 50V, 5% 137127-394
C114, 214 .0047uF, BOX, 85, 100V,
5%
137127-472
C115, 215 .022uF, BOX, 85, 100V, 5% 137127-223
C116, 216, 459 .0022uF, BOX, 85, 100V,
5%
137127-222
C120, 220 .0056uF, BOX, 85, 100V,
5%
137127-562
C121, 221, 559 .0018uF, BOX, 85, 100V,
5%
137127-182
C150, 151, 250, 251, 450, 451 .068uF, BOX, 85, 50V, 5% 137127-683
C152, 252, 452 .039uF, BOX, 85, 100V, 5% 137127-393
C155, 160, 255, 260, 406, 455, 460,
555, 560, 602, 603
27pF, 0805, COG, 50V,
5%
133622-270
C156, 157, 256, 257, 310, 311 .15uF, BOX, 85, 50V, 5% 137127-154
C158, 159, 258, 259, 718, 719 .018uF, BOX, 85, 100V, 5% 137127-183
C175, 275, 388, 475, 575, 604 1.0uF, EL, 20% 137126-1R0
C181, 281, 481, 581 10uF, EL, 85, 25V, 20% 149947-100
Capacitors
To Next Page
