40
ELECTRICAL PART LIST
Reference
Designator
Description Part
Number
Note
C300, 385, 405, 505 .1uF, BOX, 85, 50V, 5% 137127-104
C301, 550-553 .082uF, BOX, 85, 50V, 5% 137127-823
C302 680pF, MONO, COG, 50V,
5%
140564-681
C303 .056uF, BOX, 85, 63V, 5% 137127-563
C304 .0027uF, BOX, 85, 100V,
5%
137127-272
C305, 306 .22uF, BOX, 85, 50V, 5% 137127-224
C307, 453 .033uF, BOX,85,100V, 5% 137127-333
C308 .001uF, BOX, 85, 100V, 5% 137127-102
C376 100uF, EL, 105, 16V, 20% 139734-101
C377, 378 1uF, 1206, Y5V, 16V, 80% 173383-105
C389, 626-628 270pF, 0805, X7R, 50V,
10%
133623-271
C456, 457 .12uF, BOX, 85, 50V, 5% 137127-124
C506 .0033uF, BOX, 85, 100V,
5%
137127-332
C508 .012uF, BOX, 85, 100V, 5% 137127-123
C556, 557 .18uF, BOX, 85, 50V, 5% 137127-183
C605 4.7uF, EL, 20% 137126-4R7
C613 .0047uF, DISC, 60, AC 149016
C617 22uF, EL, 20% 137126-220
Capacitors (continued)
To Next Page
