5
SPECIFICATIONS
Dimensions: Module:
Satellite:
23.3"W x 7.5"D x 14.0"H
(59 x 19 x 35.5cm)
2.2"W x 3.2"D x 4.4"H
(5.6 x 8.1 x 11.2cm)
Weight: Module:
Satellite:
Packed System:
33 lb. (15kg.)
1 lb. (0.5kg.)
27 lb. (12.3kg.)
Module:
Satellites:
2
2
5-1/4" Woofers, 8Ω (parallel)
2-1/4" Twiddlers™ (each satellite)
Finish: Module:
Satellites:
Black or White, scratch-resistant,
satin-finish
Black or White, painted polymer
finish
Amplifier Power: Bass Channel: 80W maximum into 4Ω resistive load,
≤0.2% THD, from 40Hz-200Hz
Left/ Center/Right Channels: 40W maximum into 4Ω resistive load,
≤0.2% THD, from 200Hz-15kHz
Surround Channel: 20W Maximum into 4Ω resistive load,
≤0.2% THD, from 200Hz-15kHz
All Channels driven: 50W (Bass), 50W (surround),
25W (Left/Center/Right),
≤0.2% THD
Input Impedance: System:
Module:
Satellites:
8.3kΩ
4Ω (8Ω woofers wired in parallel)
8Ω (4Ω Twiddlers wired in series)
Output Noise: A-weighted for Satellite channels <300µVrms
Output Hum: Unweighted for bass channel <2mVrms
Channel Separation: (Center and Surround)
(Volume set at Maximum)
@210Hz >20dB
>20dB
Port Tuning Frequency: Small Chamber:
Large Chamber:
110Hz
37Hz
Input Sensitivity: @1kHz produces maximum rated
power in L/R channel outputs
(at full volume)
.310Vrms input
Turn-On Delay:
(Auto)
(time to speaker unmute) 1.1 ± .2 seconds
Turn-Off Delay: (time to speaker mute) .5 ± .1 seconds
Main Voltage: 120Vrms 60Hz
220/240Vrms, 50Hz
120/240Vrms
US version (configurable on PCB)
Euro version (configurable on PCB)
International version (with voltage
select switch)
Power Consumption: @ nominal mains voltage 350W (max. power)
Standby Power
Consumption: @ nominal mains voltage 15W
