ELECTRICAL PART LIST
Miscellaneous
Reference
Designator
Description Part
Number
Note
J1 HEADER 134290-05
J2, 8 CONN, HEADER, RTANG, JST 16
FEST
191169-16
J3 CONN, HEADER, RTANG, JST S2P-
VH
190552-02
J4 CONN, HEADER, RTANG, 2.5mm 145402-08
J5 CONN, DIN, RTANG, 8 POS 176198
J6 CONN, HOUSING, AC, 2 POS,
FEMALE
146563
J7 CONN, HEADER, 5 POS. 178742-5
J9, 11 CONN, PHONO JACK 180567or260382-001
J10 CABLE, FLAT, 8P, 24AWG 190701-001
Y601, 602 (120V) JUMPER, 22AWG, INSUL, 7mm 135091-070
F1 FUSE CLIP, 5mm 178548
L600 INDUCTOR, LM4532, 1uH 178370-1R0
F601 FUSE, 5X20mm, SLO-BLO, 3M 263401-3000 3
R5, 6 20 OHM, FUSING, 1/4W 130102-200 3
R14 THERMISTOR, 20K, ERTD 3FH L 203 177557
R50, 306 POT, DUAL, 10K, DETENT. 185173
R100, 200, 645 1.0KΩ, ARRAY, SMT, 4 POS, 5% 186433-1024
R130, 230, 400, 500, 704, 711,
727
3.9KΩ, ARRAY, SMT, 4 POS, 5% 186433-3924
R136 1.0 MΩ, ARRAY, SMT, 4 POS, 5% 186433-1054
R167, 567 300Ω, ARRAY, SMT, 4 POS, 5% 186433-3014
R608, 638, 700 100KΩ, ARRAY, SMT, 4 POS, 5% 186433-1044
R664 100 OHM, FUSING, 1/4W 121243-
1211015
3
X600 CRY, CER, ONATOR, 8mHz 175627
