32
Transistors (continued)
ELECTRICAL PART LIST
Amplier PCB Assembly
Reference
Designator
Description Part Number Note
Q422 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q423 MFET, N-CH, 60mA, 200V, SOT-23 354011-0010
Q424 MFET, N-CH, 60mA, 200V, SOT-23 354011-0010
Q425 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q426 PNP, LO SAT, 30V, 5.5A, SOT89 326379-0010
Q427 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q428 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q429 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q430 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q431 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q432 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q433 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Q434 DIRECTFET, N-CH, 200V, 19A, MZ 326382-0010
Integrated Circuits
Reference
Designator
Description Part Number Note
U100 LOGBUS XCVR, 1B, 3S, 74LVC1T45, SOT 759041-0010
U101 OP AMP, DUAL, JFET, TLE2072A, SO8 326336-0231
U102 SCHMIT TRIG, IN, 74HC14, SO14 260624
U103 COUNTER, SYNCHRONOUS BINARY, 4-BIT 727921-0010
U104 OP AMP, QUAD, SO-14, TL074BCDT 188953-001
U200 OP AMP, QUAD, FET INPUT, 4134, 14SOIC 330248-0010
U201 SWITCH, ANALOG, TRIPLE, ADG1433, 16TSSOP 326367-0010
U203 OP AMP, QUAD, FET INPUT, 120uV, 4140, 14SO 757494-0404
U204 COMPARATOR, DUAL, LM2903, 8SOIC 322174-0010
U205 COMPARATOR, 5.5V, 4.5nS, TLV3502, SOT23-8 353940-0010
U206 COMPARATOR, 5.5V, 4.5nS, TLV3502, SOT23-8 353940-0010
U300 HALL-EFFECT CURRENT SENSOR, ACS711, 8SO 330390-0010
U301 OP AMP, QUAD, JFET, TLE2074, SO16W, 3mV 326336-0040
U302 SWITCH, ANALOG, SPST, ADG452, 16TSSOP 328693-0010
U303 POWER STAGE AMPLIFER, 2X15W, 32HTSSOP 353939-0010
U304 COMPARATOR, QUAD, LM2901, 14SOIC 310919-001
U400 HALL-EFFECT CURRENT SENSOR, ACS711, 8SO 330390-0010
VR100 3 TERM ADJ REG, LM317MQDCYR 271642-001
VR101 3 TERM ADJ REG, LM317MQDCYR 271642-001
VR102 VOLT REG, POS, LDO, 3A, ADJ, LD1085, DPAK 362098-0010
VR103 VOLTAGE REG, NEGATIVE, LM337, SOT-223 328992-0010
