Miscellaneous
ELECTRICAL PART LIST
Amplier PCB Assembly
Reference
Designator
Description Part Number Note
HS100 HEAT SINK, DPAK 320438-002
HS300 HEAT SINK, D2PAK 320438-001
J100 CONN, FFC, 0.5mm, T ENTRY, 20POS, WHT 269863-020
J101 CONN, FFC, 0.5mm, T ENTRY, 10POS, WHT 269863-010
J300 CONN, HEADER, INLINE, PCB MNT, 4P 133220-04
J400 CONN, HEADER, INLINE, 3P, BLACK 133220-103
Y100 OSCILLATOR, 5.6MHz, 25PPM, 3.3V, 3225 757550-5M60000
- HEATSINK, TOP, AMP 732979-0010
- THERMAL PAD, AMP 720281-0010 Qty. 2
- SCREW, M3 X 8MM, SKT HD CAP 473028-0010 Qty. 3
- HEATSINK, BOTTOM, AMP 623674-0010
