Bose PowerShare PS404A

40
Reference
Designator
Description Vendor Part Number Note
C318 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C319 CC, 50V, 0.1uF, 10%, 0805, 1.2X2.0 150F-104KBD
C324 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C325 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C326 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C327 CC, 50V, 0.1uF, 5%, 0603 150F-104JAC
C331 CC, 50V, 0.47uF, 10%, 0805, 1.25X2, X7R 150F-474KBD
C333 CC, 50V, 100pF, 5%, 0603, C0G 150F-101JAC
Capacitors (continued)
ELECTRICAL PART LIST
SMPS PCB Assembly
Inductors
Reference
Designator
Description Vendor Part Number Note
L200 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L201 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L202 FERRITE-BEAD, 2.0X1.2, 0805, 300R/100MHZ, 3A 1808-0913
L203 FERRITE-BEAD, 2.0X1.2, 0805, 300R/100MHZ, 3A 1808-0913
L204 FERRITE-BEAD, 2.0X1.2, 0805, 300R/100MHZ, 3A 1808-0913
L207 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L211 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
Diodes
Reference
Designator
Description Vendor Part Number Note
BR200 DIODE, BRIDGE, 600V, 15A, GB, U15J, RL 480U-15J0
D200 DIODE, IN5408-B, 3A, 1000V 4805-4080
D201 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A, SMD, PANJIT 480S-K160
D202 DIODE, SCHOTTKY, 650V, 6A, IDH06G65C5, TO-220, RL 4806-5C50
D203 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT, ITO-220AB, RL 4800-FCT0
D204 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT, ITO-220AB, RL 4800-FCT0
D205 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT, ITO-220AB, RL 4800-FCT0
D206 DIODE, SCHOTTKY, 200V, 20A, MBR20200FCT, ITO-220AB, RL 4800-FCT0
D207 DIODE, SCHOTTKY, 40V, 2A, SK24, SMB, SM, PANJIT 480S-K240
D208 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D209 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB, CASE403A, SM 4806-0T30
D210 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB, CASE403A, SM 4806-0T30
D211 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB, CASE403A, SM 4806-0T30
D212 DIODE, ULTRA, 600V, 1A, MURS, 160T3, SMB, CASE403A, SM 4806-0T30
D213 DIODE, SUPPRESSOR, 200V, P6KE200A, AT 4802-00A0
D214 DIODE, 600V, 1A, 75NS, US1J, SOD124 480U-S1J0
D215 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190
D216 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
