Bose PowerShare PS404A

41
Reference
Designator
Description Vendor Part Number Note
D217 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D218 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D219 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D222 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D223 DIODE, RECT, 200V, 2A, ER2D, SMB/DO-214AA 480E-R2D0
D224 DIODE, RECT, 200V, 5A, ER502, AT 480R-5020
D225 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D226 RECTIFIER, ES1D, 200V, 1.1A, SMD 4840-9190
D227 DIODE, FAST, 75V, 0.5A, BAS316, SOD323, SM 480S-3160
D229 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D230 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D232 DIODE, SCHOTTKY, SK16, DO-214AA, 60V, 1A, SMD, PANJIT 480S-K160
Z200 DZ, 1/2W, 15V, 5%, SOD-123C, MMSZ5245BT1G 4837-15V9
Z201 DZ, 1/2W, 18V, 5%, SOD-123C, MMSZ5248BT1G 4837-18V9
Z202 DZ, 1/2W, 11V, 0.6V, BZX84JC11, SOD323F, SM, PHILIPS 4837-1103
Z203 DZ, 1/2W, 18V, 5%, SOD-123C, MMSZ5248BT1G 4837-18V9
Z204 DZ, 1/2W, 15V, 5%, SOD-123C, MMSZ5245BT1G 4837-15V9
Z205 DZ, 1/2W, 11V, 0.6V, BZX84JC11, SOD323F, SM, PHILIPS 4837-1103
Diodes (continued)
ELECTRICAL PART LIST
SMPS PCB Assembly
Transistors
Reference
Designator
Description Vendor Part Number Note
Q200 MOSFET, N-CH600V, TK20A60U20A, TO-220F, RL, TOSHIBA 490A-60U0
Q201 MOSFET, N-CH600V, TK20A60U20A, TO-220F, RL, TOSHIBA 490A-60U0
Q202 MOSFET, N-CH, 100V, IRLR3110, 63A, D-PAK, SM 4903-1100
Q203 TR, 3904, HFE, 100-300, SM 4860-0640
Q204 MOSFET, N-CH, 100V, IRLR3110, 63A, D-PAK, SM 4903-1100
Q205 TR, NPN, BCP56-10, SOT223 485C-P560
Q206 MOSFET, N-CH, 800V, 08N808A, TO220, RL 4908-N800
Q207 TR, 3904, HFE, 100-300, SM 4860-0640
Q208 TR, 3904, HFE, 100-300, SM 4860-0640
Q209 MOSFET, N-CH, 650V, STP28N60M2, 22A, TO-220, RL 4906-0M20
Q210 TR, MMBTA92, PNP, SOT23, KEC 4860-5360
Q211 TR, NPN, BCP56-10, SOT223 485C-P560
Q212 MOSFET, N-CH, 60V, 115MA, 2N7002, SOT-23, SM 4907-0020
Q213 TR, 3904, HFE, 100-300, SM 4860-0640
Q214 TR, 3904, HFE, 100-300, SM 4860-0640
Q215 TR, 3904, HFE, 100-300, SM 4860-0640
Q217 TR, 3906, PNP, SM 4853-9060
