Bose PowerShare PS404A

59
Transistors
ELECTRICAL PART LIST
DSP PCB Assembly
Reference
Designator
Description Vendor Part Number Note
Q600 TR, PNP, 2SA2058, HFE:125, 2-3S1A, SM 4852-0580+3
Integrated Circuits
Reference
Designator
Description Vendor Part Number Note
U600 IC, DG211BDY-T1-E3, ANA, SW, 50OHM, SPST, 4CH, SO16 3133-0661+0
U601 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U602 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U603 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U604 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U605 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U606 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U607 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U608 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U609 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U610 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U611 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U612 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U613 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U614 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U615 IC, NJM2068M, OPAMP, QUAD, +/-18V, AUD, 27M, 6V/US, DMP8 3130-6890+0
U616 IC, CS4272-CZZR, ADDA, 2CH, 24BIT, 192K, 114DB, TSSOP28 3132-4471+0
U617 IC, CS4272-CZZR, ADDA, 2CH, 24BIT, 192K, 114DB, TSSOP28 3132-4471+0
U618 IC, ADAU1450WBCPZ, DSP, FIX, 147MHZ, 8KWORD, LFCSP72 3132-9471+0
U619 IC, SN74LVC3G34DCUR, BUFFE, R, TRIPLE, VSSOP8 3133-1431+0
U620 IC, SN7815D, REG, 15V, 1A, TO-252 3132-8161+0-49
U621 IC, SN7915D, REG, -15V, 1.5A, TO-252 3132-8171+0-49
U622
IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT53
3
3132-7831+0
Miscellaneous
Reference
Designator
Description Vendor Part Number Note
J600 FFC, CONN., 30PIN, P1.0, TOP, ENTRY 2101-3073+0
J601 DIN SOCKET, M, 12P, P5, 300V, 15A, L=60, GREEN, RA 2113-3482+0
J603 CONN, FFC, 10P, P0.5, SMT, ST, F 2101-3375+1
J604 CONN, FFC, 10P, P0.5, SMT, ST, F 2101-3375+1
J605 MICRO, USB, F, 5P, P0.65, 5V, 2A, 8X5.74X3, LEADERWISE 2113-3460+0
J608 WIRE-CONN, 1P, #18, UL1007, L=30, BK, S4/S6 7013-5930+0
