Bose PowerShare PS404A

60
Resistors
ELECTRICAL PART LIST
LED PCB Assembly
Reference
Designator
Description Vendor Part Number Note
R900 RMG, 1/16W, 47R, 1%, 0603 4723-470A+P
R901 RMG, 1/16W, 47R, 1%, 0603 4723-470A+P
R904 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R905 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R906 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R907 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R908 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R909 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R910 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R911 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R912 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R913 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R914 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R915 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R916 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R917 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R918 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R919 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
R921 RMG, 1/16W, 220R, 1%, 0603/1608 4723-221A+P
R922 RMG, 1/16W, 1.5K, 1%, 0603, HK, RESISTOR/SAMSUNG 4723-152A+P-R
Capacitors
Reference
Designator
Description Vendor Part Number Note
C900 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C901 CC, 50V, 0.1U, 5%, 0603 150F-104J+P-AC
C902 CC, 50V, 1000P, 5%, 0603, X7R 150F-102J+P-AC
C903 CC, 50V, 0.01uF, 10%, 0603, X7R 150F-103K+P-AC
C904 CC, 16V, 1U, 10%, 0603, 0.8X1.6 150D-105K+P-AC
Diodes
Reference
Designator
Description Vendor Part Number Note
D900 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D901 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D902 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D903 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D905 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D906 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D907 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D908 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
D909 LED, SP, 3X5, RD/GN, SUPER, WHITE, DIFFUSED, EVERLIGHT 3700-2861+RG
