Bose PowerShare PS404A

61
Integrated Circuits
ELECTRICAL PART LIST
LED PCB Assembly
Reference
Designator
Description Vendor Part Number Note
U900
IC, CD74HC4094, SHIFT REG, 8 BIT, SIPO, 33NS, SO1
6
3132-4431+0
U901 IC, CD74HC4094, SHIFT REG, 8 BIT, SIPO, 33NS, SO16 3132-4431+0
Miscellaneous
Reference
Designator
Description Vendor Part Number Note
J900 WIRE-CONN, 10P, P2.0, #26, U, L1007, 485, RD/WH, F/M, HST 7013-4910+0
Capacitors
EQ Output PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
C950 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C951 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C952 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C953 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C954 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C955 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C956 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C957 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C960 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C961 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C962 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C963 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C964 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C965 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C966 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
C967 CC, 630V, 1000P, 10%, 1206 150M-102K+6-CF
Inductors
Reference
Designator
Description Vendor Part
Number
Note
L950 CHOKE, COMMON, MODE, 40U, +/-10%, 10A, TC1305, MI 1805-0450+0
L951 CHOKE, COMMON, MODE, 40U, +/-10%, 10A, TC1305, MI 1805-0450+0
L960 CHOKE, COMMON, MODE, 40U, +/-10%, 10A, TC1305, MI 1805-0450+0
L961 CHOKE, COMMON, MODE, 40U, +/-10%, 10A, TC1305, MI 1805-0450+0
