Bose PowerShare PS404A

62
ELECTRICAL PART LIST
Miscellaneous
EQ Output PCB Assembly
Reference
Designator
Description Vendor Part
Number
Note
ENCODER840 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10, COPAL 5200-5097+0-27
ENCODER841 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10, COPAL 5200-5097+0-27
ENCODER842 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10, COPAL 5200-5097+0-27
ENCODER843 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10, COPAL 5200-5097+0-27
ENCODER844 ENCODER, ROTARY, 10P1T, DC50V, 0.1A, 10X10, COPAL 5200-5097+0-27
J848 RJ45, F, 8P, P2.54, 12VAC, 1.5A, 17X16, SIL, ST 2113-3451+0
J852 CONNECTOR, PIN, HEADER, 4P, P2.54, ST, M, L=15 2101-3295+0
J853 CONNECTOR, PIN, HEADER, 4P, P2.54, ST, M, L=15 2101-3295+0
J952 WIRE-CONN, 4P, P3.96, #18, U, L1007, L=300, F/M, FERRITE 7013-5270+0
J953
WIRE-CONN, 4P, P3.96, #18, U, L1007, L=210, F/M, FERRIT
E
7013-5271+0
J966 DIN, SOCKET, F, 8P, P5.08, 300V, 12A, 41.16, GREEN 2113-3456+0
SW840 SW, DIP, SPST, 24V, 25MA, P2.54, 8P 5200-5084+0
