ELECTRICAL PART LIST
Inductors
AmpLink PCB Assembly, PS404A Amplier
Reference
Designator
Description Vendor Part Number Note
L400 INDUCTOR, 10UH, 20%, 7X7, X4.5, CER7042BA-100M, SM 1803-01523
L401 INDUCTOR, 10UH, 20%, 7X7, X4.5, CER7042BA-100M, SM 1803-01523
L402 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L403 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L404 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L405 FERRITE, BEAD, CHIP, SEBW201209U121MT, 0805 1808-0872
L406 INDUCTOR, 2.2UH, 20%, 3X3X, 1.2, 1.1A, SM 1803-00643
L407 FERRITE, CHIP, 0603, BLM18AG102SN1D, MURATA 1808-0878
Diodes
Reference
Designator
Description Vendor Part Number Note
D400 DIODE, SCHOTTKY, 40V, 2A, SK24, SMB, SM, PANJIT 480S-K240
D401 DIODE, SCHOTTKY, SK16, DO-, 214AA, 60V, 1A, SMD, PANJIT 480S-K160
D402 DIODE, SCHOTTKY, 40V, 2A, SK24, SMB, SM, PANJIT 480S-K240
D403 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D404 DIODE, BAV99, SOT23, PHILIPS 4840-8970
D405 LED, SMD, 2.0X1.25X0.8, RD, SUPER, EVLITE 3700-7839
D406 DOUBLE, DIODE, BAT54S, SOT-23, SCHOTTKY, SMD 480T-54S0
D407 DIODE, 1SS355TE-17, ROHM 4840-1660
Transistors
Reference
Designator
Description Vendor Part Number Note
Q1 TR, 3904, HFE, 100-300, SM 4860-0640
Q400 TR, KTA1504Y 4851-504Y
Q401 TR, 3904, HFE, 100-300, SM 4860-0640
Q402 TR, 3904, HFE, 100-300, SM 4860-0640
Integrated Circuits
Reference
Designator
Description Vendor Part Number Note
U400 IC, LPC11U35FBD48/401, MCU, 32-BIT, W_USB, LQFP48 3132-9481
U401 IC, MX25L4006EM1I-12G, FLASH, 4MBIT, SOP8 3132-8711
U402 IC, NCP301LSN09T1G, RESET, 0.9V2%, 20-66MS, SOT235 3133-1521
U403 IC, CD74HC4067M96, MUX, SO24 3132-3021
U404 IC, TPS54331DR, REG, SW, ADJ, 3A, SO8 3132-949116
U405 IC, TPS54331DR, REG, SW, ADJ, 3A, SO8 3132-949116
U406 IC, SN65MLVD203DR, M-LVDS, RX, TX, EIA899, SO14 3133-1421
U407 IC, SN65MLVD203DR, M-LVDS, RX, TX, EIA899, SO14 3133-1421
U408 IC, SN65MLVD203DR, M-LVDS, RX, TX, EIA899, SO14 3133-1421
U409 IC, SN74LVC2G17DCKR, BUFFE, R, DUAL, ST, SC70-6 3132-7450
