ELECTRICAL PART LIST
Integrated Circuits (continued)
AmpLink PCB Assembly, PS404A Amplier
Reference
Designator
Description Vendor Part Number Note
U410 IC, XL208-256-TQ64-C10, MC, U, 32-BIT, HI, PWR, TQFP64 3133-141164
U411 IC, SN74LVC3G34DCUR, BUFFE, R, TRIPLE, VSSOP8 3133-1431
U412 IC, LM3674MF-ADJ, REG, SW, 5.5V, ADJ, 0.6A, SOT-23 3133-1391
U413 IC, CD74HC4094, SHIFT, REG, 8BIT, SIPO, 33NS, SO16 3132-4431
U414 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831
U415 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831
U416 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831
U417 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831
U418 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831
U419 IC, TPD2E001DZDR, ESD PROTECT, 2CH, SOT533 3132-7831
U420 IC, W25X20CLSNIG, FLASH, 2MBIT, SO8 3133-140130
U421 IC, TL432BIDBZR, REG, V-REF, 2.5-36V, SOT-23 3132-769116
U422 IC, CS2100CP-CZZ, PROG, CLOCK, 3.5V, MSOP10 3133-1621
Miscellaneous
Reference
Designator
Description Vendor Part Number Note
J400 FFC, CONN., 30PIN, P1.0, TOP, ENTRY 2101-3073
J401 BRACKET, GROUNDING 4132-6221
J402 BRACKET, GROUNDING 4132-6221
J403 WAFER, 10, PIN, P2 2102-100S
J404 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J405 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J406 CONN, FFC, 20P, P0.5, SMT, ST, F 2101-3376
J407 CONNECTOR, HEADER, 7P, P2.54, ST, M, SINGLE, BODY 2101-3297
J408 HEADER, 2X3P, P2.54, ST, MALE 2101-3124
J409 12P, ST., WAFER, P=2.5, COULOMB 2102-121S
J410 RJ45, F, 8P8C, 21.1X15.9X, 13.35, W/LED, S-USA 2113-3481
J411 RJ45, F, 8P8C, 21.1X15.9X, 13.35, W/LED, S-USA 2113-3481
T400 CHOKE, COMMODE, 90R@10, 0MHZ, 100MA, 1.1R, SMD, 0504 1805-0700
T401 CHOKE, COMMODE, 90R@10, 0MHZ, 100MA, 1.1R, SMD, 0504 1805-0700
T402 CHOKE, COMMODE, 90R@10, 0MHZ, 100MA, 1.1R, SMD, 0504 1805-0700
T403 CHOKE, COMMODE, 90R@10, 0MHZ, 100MA, 1.1R, SMD, 0504 1805-0700
T404 CHOKE, COMMODE, 90R@10, 0MHZ, 100MA, 1.1R, SMD, 0504 1805-0700
T405 CHOKE, COMMODE, 90R@10, 0MHZ, 100MA, 1.1R, SMD, 0504 1805-0700
X400 CRYSTAL, 12MHZ, -40, C, SMD 2300-2430
X401
CRYSTAL, 24.576MHZ, 25PPM, 7.0X5.0X1.5, S
M
2300-3323
