PS602, PS602P, and PS604 Technical Specifications
Power Rating
PS602 PS602P PS604
Amplifier Power
1
2 x 300 W 2 x 300 W 4 x 150 W
Maximum Power per Channel 600 W @ 4-8 Ω, 70/100V 600 W @ 4-8 Ω, 70/100V 600 W @ 4-8 Ω, 70/100V
Gain (Low-Z mode) 44 dB, RCA (unbalanced) inputs; 32 dB, Euroblock (balanced) inputs
Gain (70V mode) 47 dB, RCA (unbalanced) inputs; 35 dB, Euroblock (balanced) inputs
Gain (100V mode) 50 dB RCA (unbalanced) inputs; 38 dB, Euroblock (balanced) inputs
1
All channels driven, THD+N < 0.04%, 1 kHz, 4-8 Ω, 70/100V
Audio Performance
Frequency Response 4-8 Ω: 20 Hz – 20 kHz (+/- 0.5 dB, @ 1 W)
70/100V: Same as 4-8 Ω with 50 Hz high-pass filter
Channel Separation
(Crosstalk)
> 85 dB @ 1 kHz, > 65 dB @ 20 kHz
Signal to Noise Ratio 100 dB (at rated power, A-weighted)
Audio Inputs
PS602 PS602P PS604
Input Channels 2 unbalanced, 2 balanced 2 unbalanced, 2 balanced 4 balanced
Connectors Stereo RCA, 3-pin Euroblock Stereo RCA, XLR/TRS 12-pin Euroblock
Input Impedance 10 kΩ (RCA), 20 kΩ (Euroblock, XLR/TRS)
Maximum Input Level 20 dBu (at 12 dBu sensitivity setting)
Sensitivity -10 / -2 dBu, RCA inputs; 4 / 12 dBu, Euroblock inputs (low / high sensitivity)
Audio Outputs
PS602 PS602P PS604
Outputs 2 2 4
Connectors 2-pin inverted Euroblock NL4 & binding posts 8-pin inverted Euroblock
Integrated DSP
A/D and D/A Converters 24-bit / 48 kHz
Processing Functions Standard mixer, loudspeaker EQ, 9-band PEQ, Vpeak/Vrms limiters, delay, band pass, mute/output polarity
inversion
Loudspeaker Presets Flat, DS16, DS40, DS100, FS3B, 402, 802, MA12EX, RMU105 and RMU108
Audio Latency 1 ms (any input to speaker output)
Indicators and Controls
Power LED Solid green: Power is on. Blinking green: Unit is in standby mode. Solid amber: Thermal fault. Solid red: Supply
fault.
Input Signal LED Green: Signal present. Amber: Input is near clipping. Red: Input is clipping. Solid red: Indicates a fault.
Output Limit LED Amber: Amplifier limiting an output. Blinking red: Amplifier muted from rear panel. Solid red: Indicates a fault.
Controls, Front Panel Power On/O, Output Level Control (PS602P only)
Controls, Rear Panel Amplifier mode DIP switches, loudspeaker EQ dials, output attenuators (PS602 and PS604 only)
Electrical
Mains Voltage 100 VAC – 240 VAC (±10%, 50/60 Hz)
AC Power Consumption 120 VAC: 79 W (Standby), 124 W (Max) 230 VAC: 88 W (Standby), 184 W (Max)
Mains Connector Standard IEC (C14)
Maximum Inrush Current 14.14 A (230 VAC / 50 Hz), 8.04 A (120 VAC / 60 Hz)
Protections High temperature, output short, extra high frequency (EHF), excessively low or high AC line voltage
Physical
Dimensions 44 mm H x 483 mm W x 414 mm D (1.7" H x 19.0" W x 16.3" D)
Shipping Weight PS602 and PS602P: 6.9 kg (15.3 lb); PS604: 7.8 kg (17.2 lb)
Net Weight PS602 and PS602P: 5.5 kg (12.2 lb); PS604: 6.4 kg (14.1 lb)
Cooling System Microprocessor controlled, variable speed fans, left to right air flow
General
Inputs (Control) RJ-45 remote input for volume control using the CC-1 ControlCenter zone controllers (PS602 and PS604 only),
or for connection to the CV41. USB input for configuring the amplifier with PowerShare Editor software. Mute
input control.
