MAIN PART LIST
ShowMatch
TM
Array Module Loudspeakers (refer to Figure 3)
Item
Number
Description Part Number Qty. Note
1 ASSY, GRILLE, 5 DEG, SVCE 751195-051S 1
ASSY, GRILLE, 10 DEG, SVCE 751195-101S
ASSY, GRILLE, 20 DEG, SVCE 751195-201S
2 ASSY, HORN PANEL, 70X5, SVCE 762707-541S 2
ASSY, HORN PANEL, 70X10, SVCE 762707-551S
ASSY, HORN PANEL, 70X20, SVCE 762707-561S
3 ASSY, HORN PANEL, 100X5, SVCE 762706-841S 2
ASSY, HORN PANEL, 100X10, SVCE 762706-851S
ASSY, HORN PANEL, 100X20, SVCE 762706-861S
4 LENS, WOOFER - 2
5 SCREW, M5X20, PAN HEAD, CROSS RECESSED DRV - 48
6 GASKET, WOOFER LENS, END - 2
7 SCREW, M4X15, WOOD, SS, BLK, DACROMET - 8
8 GASKET, OUTER, PANEL ADAPTER MOUNT - 2
9 PANEL, ADAPTER MOUNT - 1
10 GASKET, PANEL ADAPTER MOUNT - 1
11 WOOFER, 8 IN. 18 SOUND, SVCE 756151-001S 2
12 COMPRESSION DRIVER 770438-011S 4
13 GASKET, ADAPTER, THROAT - 4
14 BRACKET, SUPPORT, RIGGING - 4
15 SCREW, M4X10, WOOD, SS, BLK, DACROMET - 4
16 SCREW, M5X25, FLAT HEAD, HEX DRIVE - 8
17 SCREW, M5X10, PAN HEAD, CROSS RECESSED DRV - 4
18 ASSY, REAR RIGGING PLATE, RIGHT - 1
19 ASSY, LINK W/HNDL, REAR RIG - 1
20 HANDLE, LIFTING - 2
21 SCREW, BTTN HEAD CAP, M8–1.25X35MM, HEX DRV - 4
22 WASHER, LOCK, SPLIT, HIGH COLLAR - 4
23 PIN, QUICK RELEASE, 12MM DIA, 38MM, SVCE 754285-001S 2
24 PIN, CATCH, RIGGING, REAR - 5
25 ASSY, REAR RIGGING PLATE, LEFT - 1
26 BRACKET, REAR RIGGING, EXT - 1
27 ASSY, INPUT/OUTPUT PANEL, 5 DEG, SVCE 752363-011S 1
ASSY, INPUT/OUTPUT PANEL, 10 DEG, SVCE 752363-012S 1
ASSY, INPUT/OUTPUT PANEL, 20 DEG, SVCE 752363-013S 1
28 ASSY, RIGGING, FRONT LEFT - 1
29 ASSY, RIGGING, FRONT RIGHT - 1
30 PIN, QUICK RELEASE, 8MM DIA.,16MM, SVCE 757313-001S 4
31 ASSY, END CAP, 5 DEG 768863-051S 2
ASSY, END CAP, 10 DEG 768863-101S
ASSY, END CAP, 20 DEG 768863-201S
- GASKET, WOOFER, LENS END - 2
