PACKAGING PART LIST
ShowMatch
TM
DeltaQ
TM
Array Loudspeakers (refer to Figure 1)
Figure 1. ShowMatch DeltaQ Array Packaging View
2
3
1
1
4
5
6
7
8
Item
Number
Description Part Number Qty. Note
1 INSERT, PE FOAM, 5 DEG, SVCE 770357-051S 2
INSERT, PE FOAM, 10 DEG, SVCE 770357-101S
INSERT, PE FOAM, 20 DEG, SVCE 770357-201S
2 ASSY, HORN PANEL, 70X5, SVCE 762707-541S 2
ASSY, HORN PANEL, 70X10, SVCE 762707-551S
ASSY, HORN PANEL, 70X20, SVCE 762707-561S
3 ASSY, HORN PANEL, 100X5, SVCE 762706-841S 2
ASSY, HORN PANEL, 100X10, SVCE 762706-851S
ASSY, HORN PANEL, 100X20, SVCE 762706-861S
4 CARTON, MID-HIGH, SVCE 770356-001S 1
5 BUBBLE BAG, 260X350X.1MM, SVCE 770358-001S 2
6 GUIDE, INSTALL, SHOWMATCH MH LDSPKR 773791-0010 1
7 LABEL, HORN PANEL IDENTIFIER, 70 DEG - 2
8 LABEL, HORN PANEL IDENTIFIER, 100 DEG - 2
- POLYBAG, PE, 900X1500X0.04mm, SVCE 770513-001S 1
