Bose SoundDock Portable Service Manual

17
ELECTRICAL PART LIST
DSP PCB Assembly
Miscellaneous
Integrated Circuits
Reference
Designator
Description Part Number Note
U7000 IC, OP-AMP, LO-PWR, 1MHz, SC-70 302888-001
U7006 IC, INVERTER, SMD 266582-001
U7008 IC, VOLT REG, SMD, POS, SOT89, +5V 258167-05
U7010 IC, RESET, SOT-23, MAX809, 2.63V 191158-06
U7011 IC, DSP, TMS320DA705, MASKED 289857-7051
U7015 IC, FLASH, SERIAL, 1Mbit, 3.3V 307546-001
U7018 IC, MULTIPLEX/DEMULTIPLEX 2-CH 298096-003
U7019 IC, A/D CONV, 96KHz, 24BIT, AK5381 299343-001
U7020 IC, DAC, 192kHz, 24Bit, 2ch, AK4384 299344-001
U7027 IC, HI-PERFORMANCE, CPLD 298467-001
U7036 TRANSISTOR, MOSFET, P-CH, 30V 298094-001
U7037 IC, VOLT REG, SMD, POS, SOT89, 3.3V 258167-33
U7038 IC, UC, 8-BIT, FLASH BASED, SSOP 299197-677ISS
U7040 IC, DUAL BILAT, ANALOG SWITCH 299221-001
U7041 IC, VOLT REG, ADJ, 500MA, DPAK 258496-001
Reference
Designator
Description Part Number Note
J200 CONN, SMT, .5MM, 10-POS, FFC 269863-010
J201 CONN, SMT, .5MM, 8-POS, FFC 269863-008
J300 CONN, HEADER, 25-POS, TOP ENTRY, SM 253356-T25
J400 CONN, HEADER, 1mm, SMT, 20POS 301236-T020
J500 CONN, HEADER, 5-POS, TOP ENTRY,SMD 253356-T05
J800 CONN, HEADER, 25-POS, TOP ENTRY, SM 253356-T25
Y7001 CRYSTAL, 16.9344MHz, 4-PIN SMD 291429-004

Bose SoundDock Portable Specifications

General

Compatibility	iPhone 3GS 16GB, 32GB, iPhone 3G 8GB, 16GB, iPhone 4GB, iPod touch 1st &2nd gen. 8GB, 16GB, 32GB, iPod classic 80GB, 120GB, 160GB, iPod 5th gen. 30GB, 60GB, 80GB, iPod 4th gen. 20GB, 30GB, 40GB, 60GB, iPod nano 4th gen. 8GB, 16GB, iPod nano 3rd gen. 4GB, 8GB, iPod nano 2nd gen. 2GB, 4GB, 8GB, iPod nano 1st gen. 1GB, 2GB, 4GB, iPod mini 4GB, 6GB.
Product color	Black

Weight and Dimensions

Weight	2370 g
