Bose SoundDock Portable Service Manual

18
ELECTRICAL PART LIST
Capacitors (continued)
DSP PCB Assembly
Reference
Designator
Description Part Number Note
C7407 3300pF, 0603, X7R, 50V, .1% 191470-332
C7409 100pF, 0603, X7R, 50V, .1% 191470-101
C7410 330pF, 0603, X7R, 50V 191470-331
C7411 330pF, 0603, X7R, 50V 191470-331
C7427 0.1uF, X7R, 0603, 50V, 10% 191470-104
C7428 .033uF, 0603, X7R, 50V, 10% 191470-333
C7429 5pF, 0603, COG, 50V, .1% 188454-5R0
C7430 5pF, 0603, COG, 50V, .1% 188454-5R0
C7431 0.1uF, X7R, 0603, 50V, 10% 191470-104
Diodes
Transistors
Inductors
Reference
Designator
Description Part Number Note
Q7034 XSISTOR, BPLR, N, 50V, 100mA, SOT23 146817
Q7037 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q7040 XSISTOR, BPLR, N, 40V, 200mA, SOT23 146819
Q7041 XSISTOR, BPLR, P, 40V, 200mA, SOT23 148596
Q7042 XSISTOR, P, 50V, 2SA1341 146818
Q7043 XSISTOR, P, 50V, 2SA1341 146818
Reference
Designator
Description Part Number Note
L7002 330 OHM, FERRITE BD, 0603, 200MA 268373-331
L7019 330 OHM, FERRITE BD, 0603, 200MA 268373-331
L7020 330 OHM, BEAD, FERRITE, 0805, 1.5A 267539-331
Reference
Designator
Description Part Number Note
D7003 DIODE, SOT-23, BAV 99 147239
D7004 DIODE, SHOTTKY, BAT42W, SOD-123 196984-002
D7005 DIODE, SOT-23, BAV 99 147239
D7006 DIODE, SHOTTKY, BAT42W, SOD-123 196984-002

Bose SoundDock Portable Specifications

General

Compatibility	iPhone 3GS 16GB, 32GB, iPhone 3G 8GB, 16GB, iPhone 4GB, iPod touch 1st &2nd gen. 8GB, 16GB, 32GB, iPod classic 80GB, 120GB, 160GB, iPod 5th gen. 30GB, 60GB, 80GB, iPod 4th gen. 20GB, 30GB, 40GB, 60GB, iPod nano 4th gen. 8GB, 16GB, iPod nano 3rd gen. 4GB, 8GB, iPod nano 2nd gen. 2GB, 4GB, 8GB, iPod nano 1st gen. 1GB, 2GB, 4GB, iPod mini 4GB, 6GB.
Product color	Black

Weight and Dimensions

Weight	2370 g
