Page #19 background imageLoading...
Page #19 background image
19
ELECTRICAL PART LIST
Resistors
Amplifier PCB Assembly
Capacitors
Reference
Designator
Description Part Number Note
R7116 100K, 0603, .1W, 1% 191465-1003
R7224 10 OHM, 0603, .1W, 5% 199403-101
R7225 121K, 0603, .1W, 1% 191465-1213
R7226 121K, 0603, .1W, 1% 191465-1213
R7227 121K, 0603, .1W, 1% 191465-1213
R7228 121K, 0603, .1W, 1% 191465-1213
R7229 10K, 0603, .1W, 1% 191465-1002
R7230 10K, 0603, .1W, 1% 191465-1002
R7231 10 OHM, 0603, .1W, 5% 199403-101
R7234 10 OHM, 0603, .1W, 5% 199403-101
R7236 10 OHM, 0603, .1W, 5% 199403-101
R7237 10 OHM, 0603, .1W, 5% 199403-100
R7238 10 OHM, 0603, .1W, 5% 199403-101
R7239 10 OHM, 0603, .1W, 5% 199403-101
R7240 10 OHM, 0603, .1W, 5% 199403-101
Reference
Designator
Description Part Number Note
C7128
.22uF, 0805, X7R, 25V,10% 181264-224
C7129
.22uF, 0805, X7R, 25V,10% 181264-224
C7130
.01uF, 0805, X7R, 50V, 10% 286499-103
C7131
.01uF, 0805, X7R, 50V, 10% 286499-103
C7134
.1uF, 0805, X7R, 50V, 10% 286499-104
C7135
.1uF, 0805, X7R, 50V, 10% 286499-104
C7136
.1uF, 0805, X7R, 50V, 10% 286499-104
C7137
.1uF, 0805, X7R, 50V, 10% 286499-104
C7138
.1uF, 0805, X7R, 50V, 10% 286499-104
C7139
.1uF, 0805, X7R, 50V, 10% 286499-104
C7140
.1uF, 0805, X7R, 50V, 10% 286499-104
C7141
10uF, EL, SMD, 105C, 35V, 20% 255071-100V
C7146
.01uF, 0805, X7R, 50V, 10% 286499-103
C7147
1uF, EL, SMD, 105C, 50V, 20% 255071-1R0H
C7148
.22uF, 0805, X7R, 25V,10% 181264-224
C7149
.22uF, 0805, X7R, 25V,10% 181264-224
C7150
.1uF, 0805, X7R, 50V, 10% 286499-104
C7151
.1uF, 0805, X7R, 50V, 10% 286499-104
C7152
1uF, EL, SMD, 105C, 50V, 20% 255071-1R0H
C7153
1uF, EL, SMD, 105C, 50V, 20% 255071-1R0H
C7212
1uF, EL, 85C, 50V, 20% 177902-010H
C7213
1uF, EL, 85C, 50V, 20% 177902-010H
C7214
1uF, EL, 85C, 50V, 20% 177902-010H
C7215
1uF, EL, 85C, 50V, 20% 177902-010H
C7218
.1uF, X7R, 0603, 50V, 10% 191470-104
