Bose SoundDock Portable Service Manual

20
ELECTRICAL PART LIST
Capacitors (continued)
Amplifier PCB Assembly
Inductors
Integrated Circuits
Miscellaneous
Reference
Designator
Description Part Number Note
C7219
.1uF, X7R, 0603, 50V, 10% 191470-104
C7240
.01uF, EL, 105C, 25V, 20% 269823-103EZ
C7241
100pF, 0603, X7R, 50V, .10% 191470-101
C7242
3300pF, 0603, X7R, 50V, .10% 191470-332
C7243
3300pF, 0603, X7R, 50V, .10% 191470-332
C7244
3300pF, 0603, X7R, 50V, .10% 191470-332
C7245
3300pF, 0603, X7R, 50V, .10% 191470-332
C7246
3300pF, 0603, X7R, 50V, .10% 191470-332
C7247
3300pF, 0603, X7R, 50V, .10% 191470-332
C7248
3300pF, 0603, X7R, 50V, .10% 191470-332
C7250
.1uF, 0805, X7R, 50V, 10% 286499-104
C7251
.1uF, 0805, X7R, 50V, 10% 286499-104
C7252
.1uF, 0805, X7R, 50V, 10% 286499-104
C7253
.1uF, 0805, X7R, 50V, 10% 286499-104
Reference
Designator
Description Part Number Note
L7015 22uH, INDUCTOR, FIXED, 3.9A 300618-220M
L7016 22uH, INDUCTOR, FIXED, 3.9A 300618-220M
L7017 22uH, INDUCTOR, FIXED, 3.9A 300618-220M
L7018 22uH, INDUCTOR, FIXED, 3.9A 300618-220M
Reference
Designator
Description Part Number Note
U7028 IC, PWR-AMP, CLASS D, 20W 298092-001
Reference
Designator
Description Part Number Note
J7001 CONN, HEADER, 25POS, TOP ENTRY, SM 253356-T25
J7002 CONN, 2.5MM, 2 POS, FORMED 307962-001
J7003 CONN, 2.5MM, 2 POS, FORMED 307962-001
