ELECTRICAL PART LIST

Resistors

SPS (Switching Power Supply) PCB Assembly

Capacitors

Reference

Designator

Description Part Number Note

R003

10 OHM, 0603, .1W, 5% 199403-100

R004

10 OHM, 0603, .1W, 5% 199403-100

R005

1K, 0603, .1W, 5% 199403-102

R006

1K, 0603, .1W, 5% 199403-102

R007

100K, 0603, .1W, 1% 191465-1003

R013

100 OHM, 0603, .1W, 5% 199403-101

R014

30.1K, 0603, .1W, 1% 191465-3012

R015

60.4K, 0603, .1W, 1% 191465-6042

R017

2K, 0603, .1W, 1% 191465-2001

R018

100K, 0603, .1W, 1% 191465-1003

R019

2K, 0603, .1W, 1% 191465-2001

R020

121K, 0603, .1W, 1% 191465-1213

R021

100K, 0603, .1W, 1% 191465-1003

R022

9.53K, 0603, .1W, 1% 191465-9531

R023

0.10 OHM, 0805, 1/8W, 5% 304926-R10

R024

0.10 OHM, 0805, 1/8W, 5% 304926-R10

R026

1M, 0603, .1W, 5% 199403-105

R027

1M, 0603, .1W, 5% 199403-105

R028

1M, 0603, .1W, 5% 199403-105

R029

1M, 0603, .1W, 5% 199403-105

R030

1M, 0603, .1W, 5% 199403-105

R033

10K, 0603, .1W, 1% 191465-1002

R035

1M, 0603, .1W, 5% 199403-105

R037

10K, 0603, .1W, 1% 191465-1002

R038

2.2K, 0603, .1W, 5% 199403-222

R039

1M, 0603, .1W, 5% 199403-105

R040

1M, 0603, .1W, 5% 199403-105

R041

22K, 0603, .1W, 5% 199403-223

R042

12K, 0603, .1W, 5% 199403-123

R043

100K, 0603, .1W, 1% 191465-1003

R045

10K, 0603, .1W, 1% 191465-1002

R046

2.2K, 0603, .1W, 5% 199403-222

Reference

Designator

Description Part Number Note

C001

470pF, 0603, X7R, 50V, 10% 191470-471

C002

470pF, 0603, X7R, 50V, 10% 191470-471

C003

.1uF, 0805, X7R, 50V, 10% 286499-104

C004

.1uF, 0805, X7R, 50V, 10% 286499-104

C005

.1uF, x7r, 0603, 50V, 10% 191470-104

C006

.1uF, x7r, 0603, 50V, 10% 191470-104

C007

.01uF, 0603, X7R, 50V, 10% 191470-103

C008

100pF, 0603, X7R, 50V, 10% 191470-101

C009

220pF, 0603, X7R, 50V, 10% 191470-221
