Inductors

ELECTRICAL PART LIST

SPS (Switching Power Supply) PCB Assembly

Capacitors (continued)

Reference

Designator

Description Part Number Note

C010

.01uF, 0603, X7R, 50V, 10% 191470-103

C011

1000pF, 0603, X7R, 50V, 10% 191470-102

C012

1000pF, 0603, X7R, 50V, 10% 191470-102

C013

47uF, 7343, TANT,16V, LO-R, 10% 275411-476

C014

100uF, 7343, TANT, LO-R, 10% 275411-107

C015

.1uF, 0805, X7R, 50V, 10% 286499-104

C016

.1uF, 0805, X7R, 50V, 10% 286499-104

C020

.1uF, 0805, X7R, 50V, 10% 286499-104

C024

.1uF, 0805, X7R, 50V, 10% 286499-104

C025

3300pF, 0805, X7R, 50V, 10% 286499-332

C027

220uF, EL, SMD, 105, 35V, 20% 255071-221V

C028

3300pF, 0603, X7R, 50V, 10% 191470-332

C029

.1uF, X7r, 0603, 50V, 10% 191470-104

C033

3300Pf, 0603, X7R, 50V, 10% 191470-332

C037

.1uF, x7r, 0603, 50V, 10% 191470-104

C040

1uF, EL, SMD, 105, 50V, 20% 255071-1R0H

C041

1uF, EL, SMD, 105, 50V, 20% 255071-1R0H

C042

.1uF, 0805, X7R, 50V, 10% 286499-104

C043

100pF, 0603, X7R, 50V, 10% 191470-101

C049

.0082uF, 0603, X7R, 50V, 10% 191470-822

C053

.1uF, 0805, X7R, 50V, 10% 286499-104

C054

.1uF, 0805, X7R, 50V, 10% 286499-104

C056

1800pF, 0603, X7R, 50V, 10% 191470-182

C058

.1uF, X7r, 0603, 50V, 10% 191470-104

C061

100pF, 0603, X7R, 50V, 10% 191470-101

C062

100pF, 0603, X7R, 50V, 10% 191470-101

C063

220uF, EL, SMD, 105, 35V, 20% 255071-221V

Reference

Designator

Description Part Number Note

220uH, 1.0A, SMT, 20% 303213-221M

47uH, 1.1A,SMT, 20% 303222-470M

Diodes

Reference

Designator

Description Part Number Note

DIODE, SCHOTTKY, 40V, 3A, SMB 193847-001

DIODE, SWITCHING, 75V, 200mA 148582
