Bose SoundDock Portable Service Manual

23
Reference
Designator
Description Part Number Note
U1
IC, PWM, VOLTAGE CONTROLLER, TPS40200 303218-001
U2
IC, PWM, VOLTAGE CONTROLLER, TPS40200 303218-001
U5
IC, V REG, POS, 3.3V, 0.15A, LDO 299071-033
U8
IC, SENSOR, QT, 5V, QFN 300674-001
Integrated Circuits
Reference
Designator
Description Part Number Note
Q8
XSISTOR, MFET, P, SOT-23, 40V, 3.0A 303215-001
Q9
XSISTOR, MFET, P, SOT-23, 40V, 3.0A 303215-001
Transistors
ELECTRICAL PART LIST
SPS (Switching Power Supply) PCB Assembly
Miscellaneous
Reference
Designator
Description Part Number Note
J301
CONN, HEADER, 25POS, TOP ENTRY, SM 253356-T25
J303
CONN, HDR, 6POS, VERT, SMT, ZIFF 305369-T06

Bose SoundDock Portable Specifications

General

Compatibility	iPhone 3GS 16GB, 32GB, iPhone 3G 8GB, 16GB, iPhone 4GB, iPod touch 1st &2nd gen. 8GB, 16GB, 32GB, iPod classic 80GB, 120GB, 160GB, iPod 5th gen. 30GB, 60GB, 80GB, iPod 4th gen. 20GB, 30GB, 40GB, 60GB, iPod nano 4th gen. 8GB, 16GB, iPod nano 3rd gen. 4GB, 8GB, iPod nano 2nd gen. 2GB, 4GB, 8GB, iPod nano 1st gen. 1GB, 2GB, 4GB, iPod mini 4GB, 6GB.
Product color	Black

Weight and Dimensions

Weight	2370 g
