Bose SoundDock Portable Service Manual

24
ELECTRICAL PART LIST
Resistors
I/O PCB Assembly
Capacitors
Inductors
Reference
Designator
Description Part Number Note
R4000
100K, 0603, .1W, 1% 191465-1003
R4001
15K, 0805, .1W, 1% 133625-1502
R4002
39K, 0603, SMD, .1W, 5% 199403-393
R4003
39K, 0603, SMD, .1W, 5% 199403-393
Reference
Designator
Description Part Number Note
C4007
100pF, 0603, X7R, 50V 10% 191470-101
C4008
100pF, 0603, X7R, 50V 10% 191470-101
C4010
3300pF, 0603, X7R, 50V, 10% 191470-332
C4001
330pF, 0603, X7R, 50V, 10% 191470-331
C4003
330pF, 0603, X7R, 50V, 10% 191470-331
C4004
330pF, 0603, X7R, 50V, 10% 191470-331
C4006
330pF, 0603, X7R, 50V, 10% 191470-331
C4005
.1uF, 0805, X7R, 50V, 10% 286499-104
C4009
.1uF, 0805, X7R, 50V, 10% 286499-104
Reference
Designator
Description Part Number Note
L4000
BEAD, FERRITE, CHIP, 1806 256116-181
Diodes
Reference
Designator
Description Part Number Note
D4000
DIODE, SCHOTTKY, 40V, 3A, SMB 193847-001
D4002
DIODE, SCHOTTKY, 60V, 3A 307429-60
ZR4000
DIODE, ZENER, 22V 307428-22
Reference
Designator
Description Part Number Note
J4000
CONN, HEADER, 1mm, SMT, 20 POS 301236-T020
J4001
CONN, BATTERY, 8-PIN, 2.0mm 301572-008
J4002
CONN, DC PWR, JP3.5MM, COMBO 301948-001
Miscellaneous
