MAIN-I/O PCB PARTS LIST
Miscellaneous
Reference Designator Description Material Number Note
CN1 CONN, RECP, 2.54mm C, 28P, 2R, R,
SMT, ST, BL, Au
847748-0028
J1 CONN, HDR, 2.54mm C, 10P, 2R, P, TH,
RA, BLACK
847828-0010
J5 CONN, HDR, 1.5mm C, 8P, 1R, P, SMT,
ST, BEIGE
847746-0080
J8 CONN, RECP, 2mm C, 2P, 1R, R, SMT, ST 847824-0002
J9 CONN, HDR, 2.5mm C, 2P, 1R, P, SMT, ST 853441-0002
P1-P2 CONN, IO, XLR, 3POLE, ST, R, PCB
Mount
850870-0010
P3-P4 CONN, IO, 3POLE XLR, P, Sel Gold 763327-0120
USB1 CONN, IO, TYPE C, 24P, R, SMT, RA,
TMOUNT, CH2.2
853416-0010
VR1 POTENTIOMETER, VR CA 10K B
L=16.5MM
852544-0010
Y1 CRYSTAL, FUND, 3225, 10pF, 40PPM,
12.288MHz
628938-0010
SW2-SW3, SW5 SWITCH, TACT, 12V, 50mA, 250gf 850862-0010
SW4 SWITCH, TACT, 15V, 20mA, 320GF 854394-0010
T1-T2 TRANSFORMER, AUDIO, DIGITAL, DIL,
1mH
856463-0010
