MAIN-I/O PCB PARTS LIST
Resistors
Reference Designator Description Material Number Note
R100 RES, THICK FILM, 0603, 0.1W, 1%, 10 OH 857326-0181
R103, R239, R244, R253,
R259, R261
RES, THICK FILM, 0603, 0.1W, 1%, 100K 857326-0094
R133-R135, R146-R147,
R150-R151
RES, THICK FILM, 0402, 0.063W, 1%, 390
OHM
857326-0063
R143 RES, THICK FILM, 0402, 0.063W, 1%, 200
OHM
857326-0037
R164 RES, THICK FILM, 0603, 0.1W, 1%, 1K 857326-0092
R17-R19, R25-R27,
R31-R32, R34-R39,
R42-R43, R45,
R155-R156, R158-R159,
R165-R168, R170,
R173-R174, R180-R182,
R184, R188, R199-R201,
R204, R213, R229,
R231-R232, R254,
R267-R271
RES, THICK FILM, 0402, 0.063W, 1%, 33
OHM
857326-0058
R192, R195 RES, THICK FILM, 0402, 0.063W, 1%, 22K 857326-0045
R197 RES, THICK FILM, 0402, 0.063W, 1%, 120
OHM
857326-0026
R1-R2, R28-R29, R33,
R85, R97, R104, R123,
R172, R273
JUMPER, CHIP, 0603 857326-0218
R20-R23, R96, R98,
R101, R136-R141, R144,
R148-R149, R152-R153,
R157, R194, R198,
R207-R209
RES, THICK FILM, 0402, 0.063W, 1%, 10K 857326-0021
R210 RES, THICK FILM, 0603, 0.1W, 1%, 68.1
OHM
857326-0173
R211 RES, THICK FILM, 0603, 0.1W, 1%, 75
OHM
857326-0177
R220 RES, THICK FILM, 0402, 0.063W, 1%,
180K
857326-0036
R221 RES, THICK FILM, 0603, 0.1W, 1%, 240
OHM
857326-0131
R223, R230, R233-R236,
R245-R251
JUMPER, CHIP, 0805 857326-0219
R224 RES, THICK FILM, 0402, 0.063W, 1%, 36K 857326-0060
R225, R227 RES, THICK FILM, 0402, 0.063W, 1%,
43.2K
857326-0067
R226 RES, THICK FILM, 0603, 0.1W, 1%, 68K 857326-0172
R228 RES, THICK FILM, 0603, 0.1W, 1%, 3.01K 857326-0141
