15
MAIN-I/O PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R237, R240, R243, R256,
R260
RES, THICK FILM, 0603, 0.1W, 1%, 10K 857326-0093
R238, R252 RES, THICK FILM, 0402, 0.063W, 1%,
220K
857326-0046
R24 RES, THICK FILM, 0402, 0.063W, 1%,
1.2K
857326-0027
R241, R258 RES, THICK FILM, 0402, 0.063W, 1%, 47K 857326-0071
R255 RES, THICK FILM, 0402, 0.063W, 1%,
453K
857326-0068
R3, R9-R10, R16, R145,
R183, R205-R206
RES, THICK FILM, 0603, 0.1W, 1%, 6.2K 857326-0170
R30, R169, R214-R215,
R265-R266
JUMPER, CHIP, 0402 857326-0217
R4, R6, R12, R14 RES, THICK FILM, 0603, 0.1W, 1%, 3.3K 857326-0144
R40 RES, THICK FILM, 0402, 0.063W, 1%,
4.32K
857326-0066
R41, R202-R203 RES, THICK FILM, 0402, 0.063W, 1%,
2.2K
857326-0044
R44, R132, R193 RES, THICK FILM, 0402, 0.063W, 1%, 100
OHM
857326-0019
R46, R51, R57, R62 RES, THICK FILM, 0603, 0.1W, 1%, 1.8K 857326-0115
R47, R54, R58, R65,
R71, R88, R109, R126,
R222
RES, THICK FILM, 0603, 0.1W, 1%, 100
OHM
857326-0091
R48, R55, R59, R66 RES, THICK FILM, 0805, 0.125W, 1%, 100
OHM
857326-0186
R49, R52, R60, R63 RES, THICK FILM, 0603, 0.1W, 1%, 56K 857326-0167
R5, R7, R13, R15, R70,
R74, R87, R91, R108,
R112, R125, R129
RES, THICK FILM, 0603, 0.1W, 1%, 180
OHM
857326-0114
R50, R53, R61, R64,
R160-R163
RES, THICK FILM, 0603, 0.1W, 1%, 12K 857326-0101
R56, R142, R154, R171,
R212
RES, THICK FILM, 0402, 0.063W, 1%, 1K 857326-0020
R67, R79-R80, R93,
R105, R117-R118, R131,
R242
RES, THICK FILM, 0603, 0.1W, 1%, 13.7K 857326-0105
R69, R73, R86, R90,
R107, R111, R124, R128,
R178-R179, R185-R187,
R189-R190, R216
RES, THICK FILM, 0603, 0.1W, 1%, 6.8K 857326-0171
R72, R89, R110, R127 RES, THICK FILM, 0603, 0.1W, 1%, 47
OHM
857326-0159
