MAIN-I/O PCB PARTS LIST
Capacitors
Resistors (continued)
Reference Designator Description Material Number Note
R77-R78, R81-R82,
R115-R116, R119-R120
RES, THICK FILM, 0603, 0.1W, 1%, 470
OHM
857326-0154
R8, R11, R75, R84, R113,
R121
RES, THICK FILM, 0603, 0.1W, 1%, 47K 857326-0156
R99 RES, THICK FILM, 0603, 0.1W, 1%, 5.6K 857326-0166
Reference Designator Description Material Number Note
C1 CAP, EL, SMT, 105C, 16V, 20%, 220uF,
COMM
856752-
221M1CCC
C14, C20-C21, C25 CAP, C0G, 0402, 50V, 5%, 680pF, COMM 766718-681J1H
C15, C23 CAP, X7R, 0603, 50V, 10%, 1800pF,
COMM
718875-182K1H
C151, C178, C182 CAP, C0G, 0603, 50V, 5%, 100pF, COMM 780788-101J1H
C17, C27-C28, C30, C33,
C35, C38, C40, C42,
C46-C50, C66, C72-C76,
C106, C109, C128-C129,
C135, C138, C141,
C149-C150, C158-C159,
C163, C170-C171, C177,
C188, C193-C194, C200,
C204-C206, C220
CAP, X7R, 0402, 25V, 10%, 0.1uF, COMM 718866-104K1E
C174 CAP, C0G, 0402, 50V, 5%, 47pF, COMM 766718-470J1H
C189, C207 CAP, X7R, 0603, 50V, 10%, 0.22uF, COMM 718875-224K1H
C19, C22, C65, C68,
C82, C85, C95, C99,
C117, C121
CAP, C0G, 0402, 50V, 5%, 470pF, COMM 766718-471J1H
C190 CAP, C0G, 0603, 50V, 5%, 82pF, COMM 780788-820J1H
C26, C164, C191-C192,
C195, C202-C203, C214
CAP, EL, SMT, 105C, 25V, 20%, 100uF,
COMM
856752-
101M1ECC
C2-C3, C8-C9, C16, C29,
C32, C36-C37, C44-C45,
C52-C53, C55-C56,
C130-C131, C136, C140,
C144, C210-C213,
C217-C218
CAP, X7R, 0603, 6.3V, 10%, 4.7uF, COMM 718875-475K0J
C31, C139 CAP, C0G, 0402, 50V, 5%, 1000pF, COMM 766718-102J1H
C34 CAP, X7R, 0402, 16V, 10%, 0.022uF,
COMM
718866-223K1C
C4-C5, C10-C11,
C39, C41, C43, C51,
C132-C133, C154-C157,
C160, C173, C183
CAP, X7R, 0402, 50V, 10%, 10000pF,
COMM
718866-103K1H
