Bose Sub2 User Manual

17
MAIN-I/O PCB PARTS LIST
Capacitors (continued)
Diodes
Reference Designator Description Material Number Note
C54 CAP, X7R, 0603, 50V, 10%, 150pF, COMM 718875-151K1H
C57 CAP, X7R, 0402, 16V, 10%, 5600pF,
COMM
718866-562K1C
C58, C169, C208 CAP, C0G, 0402, 50V, 5%, 22pF, COMM 766718-220J1H
C59-C60 CAP, C0G, 0402, 50V, 5%, 15pF, COMM 766718-150J1H
C61, C67, C78, C84,
C92-C93, C100-C101,
C114-C115, C122-C123
CAP, C0G, 0402, 50V, 5%, 220pF, COMM 766718-221J1H
C62, C70, C79, C87,
C89, C102, C107, C111,
C124
CAP, EL, SMT, 105C, 16V, 20%, 22uF,
COMM
856752-
220M1CBB
C64, C81 CAP, C0G, 0603, 50V, 5%, 2700pF, COMM 780788-272J1H
C6-C7, C12-C13 CAP, X5R, 0603, 10V, 10%, 4.7uF, COMM 718835-475K1A
C83, C142, C175-C176,
C179-C180, C196-C199,
C215-C216
CAP, X5R, 0603, 25V, 10%, 4.7uF, COMM 718835-475K1E
C88, C94, C97, C105,
C110, C116, C119, C127
CAP, C0G, 0402, 50V, 5%, 100pF, COMM 766718-101J1H
C90, C103, C112, C125 CAP, C0G, 0603, 50V, 5%, 1200pF, COMM 780788-122J1H
Reference Designator Description Material Number Note
D19 DIODE, SCHOTTKY, 2A, 60V, SOD123F 852398-0010
D1-D4, D6-D7, D11-D12,
D14-D16, D23-D24
VARISTOR, MULTILAYER, 0402, 130pF,
12V
855757-
120M131
D20-D21 DIODE, SCHOTTKY, 40V, 1A, SS14L,
FLSMA
855980-0040
D30-D31 DIODE, SWITCHING, 100V, 0.15A,
SOD323F
856395-0010
D5, D8, D10, D13, D22,
D26-D29
DIODE, SW, 75V, 0.3A, SOT-23, BAV99 747976-0010
LED16-LED21, LED24 DIODE, LED, 0603, WHITE, VERT 851300-0010
LED22 DIODE, LED, 0603, RED, GREEN, VERT 851301-0010
LED23 DIODE, LED, 0606, WHITE, RED, VERT 851297-0010
