Bose Sub2 User Manual

21
POWER-AMP PCB PARTS LIST
Resistors
Reference Designator Description Material Number Note
R108 RES, THICK FILM, 0603, 0.1W, 1%, 30.9K 857326-0142
R109 RES, THICK FILM, 0603, 0.1W, 1%, 133K 857326-0104
R10X, R10Y, R11X, R11Y RES, THICK FILM, 0603, 0.1W, 1%, 22
OHM
857326-0130
R112, R143, R181 RES, THICK FILM, 0603, 0.1W, 1%, 4.7K 857326-0155
R113, R147, R16X, R16Y RES, THICK FILM, 0603, 0.1W, 1%, 3.3K 857326-0144
R115, R125 RES, THICK FILM, 0805, 0.125W, 1%, 33
OHM
857326-0190
R116, R128, R210, R213 RES, THICK FILM, 0603, 0.1W, 1%, 1M 857326-0095
R120 RES, THICK FILM, 0603, 0.1W, 1%, 18.2K 857326-0117
R129 RES, THICK FILM, 0603, 0.1W, 1%, 75
OHM
857326-0177
R12X, R12Y, R14, R14Y,
R7X, R7Y, R9X, R9Y
RES, THICK FILM, 0603, 0.1W, 1%, 8.2K 857326-0178
R132 RES, THICK FILM, 0603, 0.1W, 1%, 20
OHM
857326-0123
R138, R153 RES, THICK FILM, 0603, 0.1W, 1%, 75K 857326-0176
R140-R141, R150, R167,
R263
RES, THICK FILM, 0603, 0.1W, 1%, 1K 857326-0092
R144 RES, THICK FILM, 0603, 0.1W, 1%, 16.5K 857326-0113
R145 RES, THICK FILM, 0603, 0.1W, 1%, 51K 857326-0163
R149 RES, THICK FILM, 0603, 0.1W, 1%, 43K 857326-0153
R151, R265 RES, THICK FILM, 0603, 0.1W, 1%, 2K 857326-0119
R156 RES, THICK FILM, 0603, 0.1W, 1%, 68K 857326-0172
R157, R13X, R13Y, R4X,
R4Y
RES, THICK FILM, 0603, 0.1W, 1%, 4.7
OHM
857326-0185
R158 RES, THICK FILM, 0603, 0.1W, 1%, 3.01K 857326-0141
R159-R161 RES, THICK FILM, 1206, 0.25W, 1%, 240K 857326-0205
R15X, R15Y RES, THICK FILM, 0603, 0.1W, 1%, 1.8K 857326-0115
R168, R177-R179, R242 RES, THICK FILM, 1206, 0.25W, 1%, 2.2
OHM
857326-0214
R169-R170, R182, R211,
R222X, R222Y
RES, THICK FILM, 0603, 0.1W, 1%, 47K 857326-0156
R171, R187 RES, THICK FILM, 1206, 0.25W, 1%, 47
OHM
857326-0207
R174 RES, THICK FILM, 0805, 0.125W, 1%, 100
OHM
857326-0186
R175, R241 RES, THICK FILM, 0603, 0.1W, 1%, 1.5K 857326-0108
R176 RES, THICK FILM, 0603, 0.1W, 1%, 470
OHM
857326-0154
R186 RES, THICK FILM, 0603, 0.1W, 1%, 7.5K 857326-0175
