22
POWER-AMP PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R193-R194 RES, THICK FILM, 0603, 0.1W, 1%, 330K 857326-0145
R196, R198-R199 RES, THICK FILM, 0603, 0.1W, 1%, 470K 857326-0157
R19X, R19Y, R20X,
R20Y, R21X, R21Y,
R22X, R22Y
RES, THICK FILM, 1206, 0.25W, 1%, 10K 857326-0196
R203X RES, THICK FILM, 0603, 0.1W, 1%, 330
OHM
857326-0143
R203Y RES, THICK FILM, 0603, 0.1W, 1%, 360
OHM
857326-0148
R207 RES, THICK FILM, 0603, 0.1W, 1%, 47
OHM
857326-0159
R209 RES, THICK FILM, 1206, 0.25W, 1%, 680
OHM
857326-0210
R214-R217 RES, THICK FILM, 0805, 0.125W, 1%, 39K 857326-0191
R218, R249, R5X, R5Y RES, THICK FILM, 0603, 0.1W, 1%, 2.2K 857326-0127
R229 RES, THICK FILM, 0603, 0.1W, 1%, 130K 857326-0103
R230 RES, THICK FILM, 1206, 0.25W, 1%, 1.3
OHM
857326-0213
R231 RES, THICK FILM, 0603, 0.1W, 1%, 150K 857326-0110
R239 RES, THICK FILM, 0603, 0.1W, 1%, 220K 857326-0129
R23X, R23Y, R24X, R24Y RES, THICK FILM, 1206, 0.25W, 1%, 20
OHM
857326-0202
R253X, R253Y RES, THICK FILM, 0603, 0.1W, 1%, 34K 857326-0147
R259X, R259Y RES, THICK FILM, 0603, 0.1W, 1%, 20K 857326-0120
R26, R33, R35, R41 RES, THICK FILM, 0603, 0.1W, 1%, 6.8K 857326-0171
R268X, R268Y, R268Z RES, THICK FILM, 0603, 0.1W, 1%, 300
OHM
857326-0139
R27, R31, R36, R39 RES, THICK FILM, 0603, 0.1W, 1%, 3.9K 857326-0151
R28, R32, R37, R40,
R122-R123
RES, THICK FILM, 0603, 0.1W, 1%, 2.4K 857326-0132
R29-R30, R52, R55, R66,
R75, R78, R80, R91,
R95, R104, R119, R124,
R131, R146, R152, R165,
R184, R189, R191, R197,
R200, R208, R219-R220,
R237, R240, R248, R250,
R254-R255, R261, R267,
R18X, R18Y, R252X,
R252Y, R25X, R25Y,
R8X, R8Y
RES, THICK FILM, 0603, 0.1W, 1%, 10K 857326-0093
R2X, R2Y RES, THICK FILM, 0603, 0.1W, 1%, 27K 857326-0136
To Next Page
