POWER-AMP PCB PARTS LIST
Resistors (continued)
Reference Designator Description Material Number Note
R34, R43, R59, R65,
R85, R90, R114, R121,
R126, R130, R163, R190,
R212, R247, R1X, R1Y
RES, THICK FILM, 0805, 0.125W, 5%, 4.7
OHM
857326-0194
R38, R42, R103, R127,
R195, R232-R234, R236,
R257, R269-R271
JUMPER, CHIP, 0603 857326-0218
R3X, R3Y RES, THICK FILM, 1206, 0.25W, 1%, 8.2K 857326-0211
R56-R57, R62-R63,
R148, R164, R166, R221
RES, THICK FILM, 1206, 0.25W, 1%, 825K 857326-0212
R58, R84, R155 RES, THICK FILM, 0805, 0.125W, 1%, 22
OHM
857326-0189
R60, R76-R77, R87 RES, THICK FILM, 0402, 0.063W, 1%,
2.2K
857326-0044
R61 RES, METAL FOIL, 1206, 1W, 1%, 0.01
OHM
755170-R010F
R64, R67 RES, METAL FOIL, 1206, 1W, 1%, 0.005
OHM
755170-R005F
R68, R79 JUMPER, CHIP, 1206 857326-0220
R69, R94, R173, R180,
R188, R201-R202, R238,
R251, R256, R258, R266
RES, THICK FILM, 0603, 0.1W, 1%, 100K 857326-0094
R6X, R6Y RES, THICK FILM, 1206, 0.25W, 1%,
49.9K
857326-0208
R70-R71, R117-R118,
R133-R134
RES, THICK FILM, 1206, 0.25W, 1%, 220
OHM
857326-0203
R72, R223-R224 RES, THICK FILM, 1206, 0.25W, 1%, 20K 857326-0200
R73-R74, R142, R262 RES, THICK FILM, 0603, 0.1W, 1%, 100
OHM
857326-0091
R81-R82, R92, R111,
R135-R137, R183,
R226-R228, R235
RES, THICK FILM, 1206, 0.25W, 1%, 2.2M 857326-0204
R83, R86, R97, R102 RES, THICK FILM, 1206, 0.25W, 1%, 2 M 857326-0201
R89, R100-R101 RES, THICK FILM, 1206, 0.25W, 1%, 3.3M 857326-0206
R93, R98, R225, R260,
R264
RES, THICK FILM, 0603, 0.1W, 1%, 22K 857326-0128
R96, R154, R162 JUMPER, CHIP, 0805 857326-0219
R99, R17X, R17Y RES, THICK FILM, 0603, 0.1W, 1%, 220
OHM
857326-0126
