POWER-AMP PCB PARTS LIST
Capacitors
Reference Designator Description Material Number Note
C103, C189 CAP, X7R, 0805, 100V, 10%, 0.033uF,
COMM
763872-333K2A
C106, C113 CAP, X7R, 0603, 100V, 10%, 220pF,
COMM
718875-221K2A
C108 CAP, X7R, 0603, 50V, 10%, 0.015uF,
COMM
718875-153K1H
C114 CAP, C0G, 0603, 50V, 5%, 100pF, COMM 780788-101J1H
C119, C128, C174 CAP, EL, POLYMER, SMT, 25V, 20%,
150uF, COMM
857020-151M1E-
BE
C124 CAP, X7R, 0805, 100V, 10%, 0.01uF,
COMM
763872-103K2A
C12X, C12Y, C1X, C1Y,
C5X, C5Y
CAP, X5R, 0603, 25V, 20%, 10uF, COMM 718835-106M1E
C135 CAP, X7R, 0603, 50V, 10%, 0.047uF,
COMM
718875-473K1H
C14, C75, C81, C121,
C127, C130, C196
CAP, X7R, 0603, 50V, 10%, 1uF, COMM 718875-105K1H
C160-C162, C170-C172 CAP, X7R, 0402, 100V, 10%, 2200pF,
COMM
718866-222K2A
C176, C197 CAP, EL, SMT, 105C, 16V, 20%, 10uF,
COMM
856752-
100M1CAB
C17X, C17Y, C18X,
C18Y, C193X, C193Y,
C194X, C194Y, C22X,
C22Y, C23X, C23Y,
C27X, C27Y
CAP, X7R, 0603, 100V, 10%, 0.1uF, COMM 718875-104K2A
C19, C72-C73, C78,
C82, C94, C115-C118,
C132-C133, C142-C143,
C149-C150, C173, C10X,
C10Y, C3X, C3Y, C7X,
C7Y
CAP, X5R, 0603, 25V, 10%, 4.7uF, COMM 718835-475K1E
C24X, C24Y CAP, FILM, LS 5mm, AMMO, 5%, 100V,
1uF
329288-1004BJA
C25X, C25Y CAP, X7R, 0805, 100V, 20%, 0.01uF,
COMM
763872-103M2A
C26X, C26Y CAP, C0G, 0805, 100V, 5%, 1000pF,
COMM
763940-102J2A
C28, C32, C34, C38 CAP, C0G, 0603, 50V, 5%, 680pF, COMM 780788-681J1H
C29-C30, C152, C154 CAP, C0G, 0603, 50V, 5%, 470pF, COMM 780788-471J1H
C31, C37 CAP, X7R, 0603, 50V, 10%, 3300pF, COMM 718875-332K1H
C4, C11, C13, C35, C40,
C104-C105, C110-C112,
C125, C138, C140, C147,
C183, C188, C190-C191
CAP, X7R, 0603, 50V, 10%, 0.1uF, COMM 718875-104K1H
