POWER-AMP PCB PARTS LIST
Capacitors (continued)
Reference Designator Description Material Number Note
C48, C62, C64 CAP, X7R, HI VOLT, 0805, 630V, 10%,
.01uF, COMM
852020-103K2J
C49-C50 CAP, EL, SNAP-IN, 450V, 20%, 330uF 853707-
331M2WCC
C52-C53, C120, C129,
C141
CAP, EL, POLYMER, SMT, 25V, 20%,
47uF, COMM
857020-
331M2WCC
C55, C67, C76, C177 CAP, FILM, PFC, 15mm, BULK 6mm, 630V,
10%, 1uF
856507-
105K2JBB
C61, C123, C159 CAP, X7R, HI V, 1206, 1000V, 10%,
4700pF, COMM
852057-472K3A
C65-C66 CAP, C0G, 0603, 50V, 5%, 47pF, COMM 780788-470J1H
C68, C70-C71, C131,
C139, C146, C6X, C6Y,
C8X, C8Y, C9X, C9Y
CAP, C0G, 0603, 50V, 5%, 1000pF, COMM 780788-102J1H
C69, C101, C107 CAP, C0G, 0603, 50V, 5%, 220pF, COMM 780788-221J1H
C74 CAP, X7R, 0603, 50V, 10%, 0.068uF,
COMM
718875-683K1H
C79 CAP, X7R, 0603, 16V, 10%, 0.47uF, COMM 718875-474K1C
C80, C102 CAP, C0G, 0805, 250V, 5%, 100pF, COMM 763940-101J2E
C83 CAP, C0G, 0603, 50V, 5%, 330pF, COMM 780788-331J1H
C85-C87, C96-C98 CAP, EL, LOW Z, 18x25mm, 80V, 20%,
820uF
853760-821M1K-
GG
C88, C91 CAP, X7R, HI VOLT, 0805, 500V, 10%,
220pF, COMM
852020-221K2H
C89, C136-C137, C175 CAP, X7R, 0603, 100V, 10%, 1000pF,
COMM
718875-102K2A
C90 CAP, C0G, HI VOLT, 1206, 500V, 5%, 15pF,
COMM
777098-150J2H
C92 CAP, X7R, 0603, 50V, 10%, 0.22uF, COMM 718875-224K1H
C93, C151, C203 CAP, X7R, 0603, 50V, 5%, 10000pF,
COMM
718875-103J1H
C99-C100 CAP, FILM, HI V, 15mm, BULK, 1000V, 5%,
0.68uF
856510-
683J3ABB
CX1-CX3 CAP, FILM, X2, LS 15mm, 305VAC, 20%,
0.47uF
310415-474MG
CY1-CY2 CAP, CER, X1/Y1, Bulk 25mm, 10%, 330pF 855444-331KG
3
CY3-CY4, CY6 CAP, CER, X1/Y1, Bulk 5mm, 20%, 1000pF 855444-102MN
3
CY5 CAP, CER, X1/Y1, Bulk 25mm, 10%, 470pF 855444-471KG
3
