POWER-AMP PCB PARTS LIST
Diodes
Reference Designator Description Material Number Note
BD1 DIODE, BRIDGE RECTIFIER, 25A, 800V,
SIP
842301-0800
D19-D21, D24 DIODE, RECT, S-FAST, 400V, 10A, TPM-
R10G, SMPC
855873-0400
D23 DIODE, ZENER, 0.2W, 15V, 5%, SOD-
323F
856094-15V0
D25-D26 DIODE, ZENER, 0.5W, 2.4V, 2%, SOD-
123F
856111-02V4
D27 DIODE, RECT, ULTRAFAST, 200V, 6A,
TPUH6D, SMPC
855862-0200
D28 DIODE, SCHOTTKY, 2A, 60V, SOD123F 852398-0010
D29, D42, D45 DIODE, ZENER, 0.5W, 5%, 24V, SOD-123 174265-5252
D3, D13-D14, D33, D35,
D43-D44
DIODE, RECT, FAST, 1000V, 0.8A,
RS1ML, FLSMA
856386-1000
D30-D31 DIODE, RECT, FAST, 1000V, 1A 317066-1000
D32, D34, D1X, D1Y,
D1Z, D2X, D2Y, D2Z
DIODE, RECT, 200V, 1A, ESH1DM, SMA 849894-0100
D36 DIODE, ZENER, 0.2W, 12V, 2%, SOD-
323F
856105-12V0
D39 DIODE, SW, 75V, 0.3A, SOT-23, BAV99 747976-0010
D4, D12, D18, D22,
D37-D38, D40, D41X,
D41Y, D41Z, D5X, D5Y,
D5Z
DIODE, SWITCHING, 100V, 0.15A,
SOD323F
856395-0010
D6X, D6Y, D6Z, D7X,
D7Y, D7Z
DIODE, RECT, SUPERFAST, 200V, 1A,
ES1D, SMA
856033-0200
D9, D11, D15, D17 DIODE, SINGLE, 600V, 5A, RFNL58M6S,
TO-252
849891-0010
LED2-LED3, LED1X,
LED1Y, LED1Z
DIODE, LED, 0603, 50mA, RED, VERT 851303-0010
ZD3-ZD5 DIODE, ZENER, 0.2W, 5.1V, 5%, SOD-
323F
856094-05V1
